EEA-PAM-533-B-32

Name: EEA-PAM-533-B-32
Brand: Vickers
Price: 359 USD
Rating: 4.5 (24 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

Call for Expedited Shipping and Product Condition Options

The EEA-PAM-533-B-32 amplifier card includes five inputs and a 0 to 20 mA current input range. The model offers automatic reset, short-circuit protection and a 0 to 10 V command input voltage.

Preparing your secure checkout page...

Warranty

Wake Industrial Warranty

Shipping

Payment

Surplus

Have a EEA-PAM-533-B-32 to sell?

To Speak to a sales representative for pricing and lead time:

Phone

1-888-551-3082

International

1-919-443-0207

sales@wakeindustrial.com

Description
Revisions
Specs
FAQ

Product Description

The eea-pam-533-b-32 is a power amplifier card produced by Eaton Vickers. For protection against damage, the model includes an automatic reset function to guard against short circuits and reverse polarity.

The amplifier EEA-PAM series amplifier card has automatic reset capabilities when the voltage exceeds 9.8 V or falls below 40 V. The command inputs for voltage range from 0 to 10 V, and the current input ranges from 0 to 20 mA. The amplifier's command signal monitor point is located on the front panel. The amplifier card is built with short-circuit protection for all outputs. It operates efficiently within a temperature range of 0 to 50 degrees Celsius and features low-temperature drift of less than 1 mV/?C. The front panel provides monitoring points and LED indicators, allowing users to monitor the amplifier's status thoroughly. Additionally, the front panel features controls to tweak specific settings to suit various needs. This EEA-PAM-533 power amplifier card utilizes low supply voltage protection and pulse width modulation for enhanced efficiency. The model also supports ramp-time adjustments, with factory settings ranging from a minimum of 50 ms to a maximum of 5 seconds.

The model eea-pam-533-b-32 features five inputs, with four dedicated to direct current and one for inverting. The device operates on a nominal DC input voltage of 24 V and a control output supply of 15 V. The amplifier accepts input voltages ranging from 20 V to 34 V, with increased protection against voltage ripples. It has an automatic shutdown mechanism when the voltage falls below 19 V. The acceptable current threshold ranges from 0 to 20 mA. Wake Industrial has this Vickers product eea-pam-533-b-32 in stock with a replacement warranty.

EEA-PAM-533-B-32 Technical Specifications

Max. Solenoid Current:	2.7 A
Dither:	Factory-set
Ramps Input:	22 kohms
Amplifier Shut-down:	<18 V DC
Nominal Power Supply:	24 V DC
Output Monitor Point Output:	10 kohms short-circuit protected
Overload Detection:	Automatic reset
Ramp-active Indicator Output:	10 kohms
Drive Input:	22 kohms
Ramp-time Adjustment (minimum):	50 ms

Frequently Asked Questions about EEA-PAM-533-B-32

Q: What are the command input options for the EEA-PAM-533-B-32?

A: The amplifier accepts voltage inputs from 0 to 10 V. It also supports current inputs ranging from 0 to 20 mA.

Q: How does the EEA-PAM-533-B-32 handle short circuits?

A: The amplifier features built-in short-circuit protection for all outputs. It includes an automatic reset function to guard against damage.

Q: What are the voltage requirements for the EEA-PAM-533-B-32?

A: The amplifier operates on a nominal DC input voltage of 24 V. It accepts input voltages between 20 V and 34 V.

Q: What temperature range can the EEA-PAM-533-B-32 operate within?

A: The amplifier operates efficiently within a temperature range of 0 to 50 degrees Celsius. It also has a low-temperature drift of less than 1 mV/?C.

Q: What are the ramp-time adjustment capabilities of the EEA-PAM-533-B-32?

A: The amplifier supports ramp-time adjustments from a minimum of 50 ms. The maximum ramp-time can be up to 5 seconds.

Internal Product Review

‘‘The EEA-PAM-533-B-32 model by Eaton Vickers is a power amplifier card featuring five inputs, automatic reset, and short-circuit protection. The model weighs 330 g and accepts input voltages of 20 V to 34 V, with current inputs from 0 to 20 mA.’’
