Home Pacific Scientific POWERMAX II M Series M22NRXC-LNN-NS-00

M22NRXC-LNN-NS-00

Name: M22NRXC-LNN-NS-00
Brand: Pacific Scientific
Price: 368 USD
Rating: 4.5 (20 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

Current response time:

4 Minutes 11 Seconds

The M22NRXC-LNN-NS-00 by Pacific Scientific is part of the PowerMax II M Motor Series. The M22NRXC-LNN-NS-00 is a NEMA mounting motor featuring a holding torque of 1.68 Nm and a rated current of 3.1 Amps DC. It also holds a phase resistance of 3.12 ohms +/- 10% and phase inductance of 3.1 mH Typical.

Preparing your secure checkout page...

Warranty

Wake Industrial Warranty

Shipping

Payment

Surplus

Have a M22NRXC-LNN-NS-00 to sell?

To Speak to a sales representative for pricing and lead time:

Phone

1-888-551-3082

International

1-919-443-0207

sales@wakeindustrial.com

Description
Revisions
Specs
FAQ

Product Description

Pacific Scientific seems to have mastered the art of consistently meeting the needs of its clients. Pacific Scientific understands the needs and demand of a product before manufacturing it. With that, it makes the desired products with the right specifications to achieve the customers’ goals. Pacific Scientific products are powerful, more rugged, future proof and quite affordable. Pacific Scientific works with an efficient group of suppliers who increase utility. You can shop for automation aftermarket accessories such as various models of electronic controllers, motors as well as drive controllers.

Pacific Scientific prowess is also seen in the Powermax II motors such as the M22NRXC-LNN-NS-00 motor. With this motor, you can enjoy exceptional durability since it has oversized 30mm bearings. This unit also features polymer encapsulated stator that enhances exceptional thermal dissipation. Better still, the M22NRXC-LNN-NS-00 unit is designed to accommodate low inertia rotor for the production of the highest acceleration possible. To increase the available torque, you may consider having the optional Sigmax Technology.

Now moving on to the technical details of the M22NRXC-LNN-NS-00 parameters. This stepper motor functions best when the rotor inertia value is 0.025kgm2 x 10-3 and the detent torque is estimated at 0.12 Nm. While the rated current is estimated at 2.3 Amps to 6.5 Amps, the holding torque (+/-10%) is 1.15 to 1.79 Nm. The M22NRXC-LNN-NS-00 stepper motor has a thermal resistance of 4.5oC/watts and the estimated phase resistance stands at 0.21 - 1.52 Ohms +/-10%. Its estimated net weight is 1.13 kgs while the phase inductance is 0.7 to 6.8 Mh.

M22NRXC-LNN-NS-00 Technical Specifications

Rated current:	2.3…6.5 A
Shaft:	Plain with sealing ring
Thermal resistance:	4.5 °C/W
Phase resistance:	0.21... 0.52 (+/-10%) Ohm
Phase inductance:	0.7… 6.8 mH
Holding torque:	1.15… 1.79 Nm (+/- 10%)
Bearing size:	30mm
Maximum installation elevation:	1000 MSL
Coating:	Prime Black Coat
Mounting style:	Flange with 04 holes

Frequently Asked Questions about M22NRXC-LNN-NS-00

Q: What kind of output shaft does the model M22NRXC-LNN-NS-00 have?

A: It is equipped with a plain output shaft with sealing ring. It also provides isolation from the impurities in the atmospohere.

Q: In what orientation the model M22NRXC-LNN-NS-00 should be mounted?

A: It allows mounting in any orientation with its four holes in flange. The motor should be tightended according to the torque specified in the user manual.

Q: Does the M22NRXC-LNN-NS-00 model comes coating?

A: It is coated with a prime black coat which prevents rusting. This isolation saves from many atmospheric effects and provides long service life.

Q: How much current does the M22NRXC-LNN-NS-00 consumes?

A: It function with a current consumption from 2.3 to a peak of 6.5 A. If operated in optimum conditions, it may consume minimum current.

Q: Is there a limit to installation height for the M22NRXC-LNN-NS-00?

A: It is allowed to be installed at a maximum height of 1000 MSL. Above this, data degradation may occur.
