The M21NRXA-LSN-M1-03 by Pacific Scientific is part of the PowerMax II M Motor Series. The M21NRXA-LSN-M1-03 is a NEMA mounting motor featuring a holding torque of 1.00 Nm and a rated current of 5.6 Amps DC. It also holds a phase resistance of 0.92 ohms +/- 10% and phase inductance of 0.70 mH Typical .

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

M21NRXA-LSN-M1-03 is a model of M series POWERMAX II designed by Pacific Scientific. Among the stepper motors available, the M series POWERMAX II is regarded as one of the most powerful. It is a hybrid step motor with vast capabilities and high efficiency with a very high-speed rage and rotating force per motor size.

The M21NRXA-LSN-M1-03 stepper motor rotates at 2.8 amps per phase and 1.80 per step (200 steps).

It comprises of double round shafts of size 0.25 inches and standing length of 3 inches.  It has a 50 W power, Base RPM of 1500, Wiring Configuration of 8-Wire, and DC Rated Current per Phase of 2.8A BIPOLAR SERIES.

The front shafts length and the rear shaft length are about 0.6 inches and 1.0 inches long respectively. M21NRXA-LSN-M1-03 makes use of NEMA Mounting NEMA size of 23. The Motor comprises of a smooth and special shaft modification and configuration. It also has a holder for winding and termination type per allotted letter.  The M21NRXA-LSN-M1-03 is compact, durable, and great to touch.

Features of M21NRXA-LSN-M1-03 stepper motor

The construction is regular with an added specification of 1 stack. It has an enhanced model type with receptacle termination with the shaft configuration and shaft modification being unique and smooth. The winding is per assigned letter with a standard rotor type. Its Encoder option comprises of encoder mounting provisions, and its sequence number is factory attached.

Before purchasing this powerful stepper motor, you should ensure it is the same size and specification to what you want to replace. This is important to ensure the efficient working of the M21NRXA-LSN-M1-03 stepper motor and prevent damage or danger.

  • M21 NRXA LSN M1 03
  • M21-NRXA-LSN-M1-03
  • M21NRXA LSN M1 03
  • M21NRXA-LSN-M1-O3
  • M21NRXALSNM103
  • M21NRXALSN-M1-03

M21NRXA-LSN-M1-03 Technical Specifications

:
Detent Torque : 0.66 Nm
Holding Torque: 1.00 Nm
Phase Inductance: 0.70 mH Typical
Phase Resistance : 0.92 ohms +/- 10%
Rated Current/ Phase: 5.6 Amps DC
Thermal Resistance: 5.5 Mounted degree Celsius/ Watt
