4VM82-000-8

Product Description

The 4VM82-000-8 is a low inertia servomotor from Pacific Scientific. It is a part of its VM series and has a model number 4. The servomotor is currently offered by Kollmorgen under their brand name. It features rated current in the range of 3.1A to 5.7A and rated voltage in the range of 18V to 36V. The motor is a type of permanent magnet DC servomotor with permanent magnets in the stator. These permanent magnets render the magnetic field rather than the windings of the stator.

The unit is a good choice for catering to the automation of motors. This is because the servomotor features high-speed reciprocating property and good braking performance. It is recommended for applications that require hard accelerations and decelerations, light load positioning, and high speed. The unit is ideal for use in cases where reliability and high-volume production cannot be sacrificed. As a low inertia device, the motor has less heat dissipation, small spindle inertia, and a compact, flat design. This flat design ensures that the device takes up minimum space at the point of installation.

The magnets used in the servomotor are designed using Alnico V-7 materials. The motor has a factory assigned sequence number. There is no provision for forced air cooling on the servo unit. The device does not come attached with other accessories like an analog tachometer or an optical encoder. The shaft diameter at the drive-end bearing journal is approximately 0.469 inches to 0.531 inches. The company gives you the PMDC servomotor with a warranty period of one year. It can be sent to any part of the world using any of the multiple delivery options.
