E4809-436-093

Product Description

The E4809-436-093 FR board from Okuma is put to use in the manufacturer’s replacement battery. The board is used in CNC machines. The product functions like a printed circuit control board. The device weighs 0.36kg. The unit features multiple conductive and insulating layers one on top of the other. It is used to fix electronic components in specific locations on its outer layers with a soldering action. This board is designed using flame retardant materials. The product primarily features a flat sheet made of insulating material along with a copper foil layer that is laminated to the substrate.

The device serves as a panel in which changes are made to the circuit. The unit comprises several components like resistors, capacitors, inductors, transistors and diodes for its working. Each of these components has its unique function. The product featuring a control board will not function as desired if this board fails for some reason. The board must be kept protected to prevent the copper in it from deteriorating and/or oxidizing. The device has a rigid and lightweight design and is easily reworkable. The unit can portray thermal shock if it is not used properly. This E4809-436-093 board is available with a one-year warranty.

The control board comes with a wide range of electrical and mechanical attributes. The product houses a thin baseboard that is just about 1.5mm thick. This base usually comprises fiberglass or resin bonded paper as the insulating material and a thinner copper layer on either one or both of its surfaces. A control board can be tested by using multimeter probes at its test points. The manufacturer Okuma has made its presence felt worldwide for the wide range of machine tools. The machine tools include lathes, grinders, machining centers, multitasking machines and more. This board is dispatched in custom military-grade packaging so that it reaches you without damage during transit.
