SRF5348-4485-84-5-45BC-CU

Product Description

Kollmorgen is an original equipment manufacturer of top-quality motion control products. The company manufactures drives, amplifiers, actuation mechanisms, gearing, classic DC motors, and various servo motors.

The SRF5348-4485-84-5-45BC-CU is a DC motor produced by the company. The motor uses permanent magnets that generate a steady magnetic field. This model has 1.2 ohms resistance with a peak current of 62 A. The motor’s armature comes with class H insulation that enables the armature to resist temperatures as high as 180 ᵒC. Class H insulations are specially designed for high-temperature applications and consist of glass fiber, asbestos, and mica. The motor comes with large bearings that are enclosed in a seal. The SRF5348-4485-84-5-45BC-CU has been designed to comply with very high standards of quality and user-friendliness. It is a washdown duty motor and is completely protected against the effects of water splashes/water jets.

The SRF5348-4485-84-5-45BC-CU permanent magnets offer a wide speed range when compared with wound field motors. This model comes with dynamic braking that helps in instantly stopping or decelerating motors. There is little to no demagnetization despite dynamic braking. The motor's torque constant is 7.9 lb-in/A. This allows a significant torque advantage and enables the motor to maintain a steady torque even at high speeds. This model has an explosion-proof design that enables users to operate the motor in extremely hazardous environments. The SRF5348-4485-84-5-45BC-CU has a 13.5 mH inductance and comes with approvals and certifications from UL, CSA, and CE. In standstill mode, the motor’s top speed is 1750 rpm, and it can produce 54 lb-in torque. The SRF5348-4485-84-5-45BC-CU also has field-replaceable brushes that come with constant force brush springs.
