SRF3756-4996-84-5-56BC-CU

Product Description

The SRF3756-4996-84-5-56BC-CU is Kollmorgen’s Permanent Magnet DC (PMDC) motor designed to produce a wider speed range and an exceptionally linear torque/speed curve. It features an explosion-proof and wash-down model, as well as cost-effective and co-engineered modifications tailored according to customer requirements.

A Permanent Magnet DC motor is actually a type of DC motor that uses a permanent magnet to create the magnetic field that is required for the specific operation of a DC motor. The main structure of this PMDC motor consists of a polyester impregnated armature winding, a rugged and fused commutator, and a number of field-replaceable brushes. The radially magnetized permanent magnets are mounted on the inner periphery of the stator core to produce the field flux. This permanent magnet fields are more efficient, lighter, smaller, and offer a wide range of torques & speeds.

The SRF3756-4996-84-5-56BC-CU PMDC motor is available with NEMA or metric mountings and will produce 1750 RPM and a pick current of 81 A with 0.5 Ω resistance. This motor features a standard 56C NEMA frame with Class H armature insulation. The notable features include compact size, acceleration torque, predictable motor speed properties, and energy efficiency. This device doesn’t need any external field current which yields it a smaller, lighter, and energy-efficient motor. The length of this motor is 13.25 inch with a weight of around 30 lbs.

The NEMA standard Kollmorgen’s SRF3756-4996-84-5-56BC-CU is UL Recognized and CSA Certified. This high-performance PMDC motor has a wide range of applications from small medical equipment to automobile industries.
