Product Description
Featured with a removable foundation, sealed bearings, and TENV type enclosure the SR3632-8292-7-56BC-CU is a 90V, DC motor from KOLLMORGEN. This 1/3 horsepower motor is designed to produce a maximum continuous torque of 12.0 lb.-in and it consumes around 3.5 amperes of current while operating in steady-state and full speed. The peak current required by this motor is 71 A and its rated resistance is 1.8 ohm. You can control the speed of this motor by coupling it to a suitably chosen SCR (silicon controlled rectifier) type motor speed controller. SCRs offer optimum control of the motor through manipulating the supply current. However, this motor can also be operated directly from a 90 VDC source if its full speed operating is desired.
The foundation of this motor and its front plate is designed to comply with NEMA 56C standards. The SR3632-8292-7-56BC-CU is a reliable, industrial-grade motor as it comes equipped with a pair of powerful brushes and a fused commutator. Similar category products in the market are seldom offered with fused commutators because fusing of commutation requires advanced technical resources. The availability of direct access to brushes is another valuable feature as it allows hustled free inspection and field replacement of the brushes. This motor use YP00565 type brushes which are easily available on the market.
By design, the SR3632-8292-7-56BC-CU is a compact motor that weighs around 21 lbs. and has a length of 10.13 inches. The TENV type enclosure of this motor makes it a viable solution for challenging industrial environments. This motor has a bigger than usual conduit box which allows easy termination of cables. The conduit box is reinforced with gaskets.
