Home Kollmorgen S300 Servo Drives S30361-NA-SB

S30361-NA-SB

Name: S30361-NA-SB
Brand: Kollmorgen
Price: 333 USD
Availability: InStock
Rating: 4.6 (17 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships 3-5 Days

Current response time:

3 Minutes 4 Seconds

The S30361-NA-SB is a compact servo amplifier from the SERVOSTAR 300 digital servo amplifier family, weighing approximately 2.6 kilograms. Manufactured by Kollmorgen as part of the S300 Servo Drives series, it supports supply voltages ranging from 110V to 230V. The device features an 8 kHz switching frequency.

Email

Phone

Part Number

+Add a message

Website

Preparing your secure checkout page...

Product Description

The S30361-NA-SB from Kollmorgen belongs to the SERVOSTAR 300 digital servo amplifier line that delivers high-performance motion control.

The servo drive stands out with its versatile power input abilities and motor support for industrial automation tasks that call for reliable performance. This device functions with single or three-phase electricity and features voltage acceptance ranging from 110V minus 10% to 230V plus 10% for single-phase and from 110V minus 10% to 230V plus 10% for each of its three-phase connections. The drive functions at both 50 and 60 Hz normal power lines to produce 1.1 kilo Volt Amps of reliable continuous power (S1). The drive works with a 450 V DC buslink system to move power and support motor capability. This product provides design specifications, including 3.5 Arms RMS current output at 115V input and 3.0 Arms RMS current output at 230V input. At 5 seconds, the S30361-NA-SB pushes 9 Arms of torque output per cycle without affecting the input power.

The drive's output stage works at 8 kHz frequency but boosts to 16 kHz mode when running at half the rated current to improve performance in delicate applications. The device shows a fast speed to boost voltage at 3.0 kV/µs under 115V conditions to deliver quick and precise control. The drive comes in a small package and only weighs 2.6 kilograms. It fits easily into cabinet setups because it measures 275 mm in height with dimensions of 70 mm wide and 171 mm deep (or under 200 mm when you include connectors). It can be purchased at Wake Industrial with a one-year warranty.

S30361-NA-SB Technical Specifications

Device Family:	SERVOSTAR 300 digital servo amplifier
Supply Voltage (three-phase):	110-230 V ±10%
Rated input power (S1):	1.1 kVA
Peak output current (5 s):	9 Arms
Rated output current (rms) at 115V:	3.5 Arms
Rated output current (rms) at 230V:	3.0 Arms
Output switching frequency (standard):	8 kHz
Output switching frequency (at 50% current):	16 kHz
Voltage rise speed (du/dt at 115V):	3.0 kV/µs
Frequency:	50/60 Hz
Depth (without connectors):	171 mm
Depth (with connectors):	<200 mm
Width:	70 mm
Height (without connectors):	275 mm
Weight:	2.6 kg
Maximum DC Bus Link Voltage:	450 V
Supply Voltage (single-phase):	110-230 V ±10%

Frequently Asked Questions about S30361-NA-SB

Q: What power input types does the S30361-NA-SB support?

A: The S30361-NA-SB supports both single-phase and three-phase power inputs with voltage ranges from 110V (-10%) to 230V (+10%), making it adaptable to various electrical systems.

Q: What are the current and power output ratings of the S30361-NA-SB?

A: It delivers 1.1 kVA continuous power with 3.5 Arms RMS current at 115V and 3.0 Arms at 230V, while reaching a peak of 9 Arms for 5 seconds per cycle.

Q: What is the switching frequency of the S30361-NA-SB’s output stage?

A: The drive operates at 8 kHz under normal conditions and boosts to 16 kHz at half rated current to enhance precision in sensitive motion control tasks.

Q: How compact is the S30361-NA-SB and what is its weight?

A: The S30361-NA-SB weighs only 2.6 kg and measures 275 mm in height, 70 mm in width, and 171 mm in depth (excluding connectors), making it ideal for tight cabinet spaces.

Q: What type of DC buslink system does the S30361-NA-SB use?

A: It operates on a 450 V DC buslink system, which helps efficiently transfer power and support the motor's performance in continuous industrial operations.
