BH-622-B-99-270

Product Description

The BH-622-B-99-270 low inertia servomotor from Kollmorgen has Class H insulation according to DIN 57530 specification. The GOLDLINE brand motor works along with the S610 SERVOSTAR servo amplifier. This product features a peak current rating of 37.7A. It also has a maximum length of 355.6mm with the brake included. The rotor has a moment of inertia of 10.3kgcm². There must be sufficient heat transfer in the motor flange and surroundings. The temperature of the flange should not exceed 65°C. The unit must not be overstressed when it is assembled or fixed in place. The synchronous motor has a warranty period of one year.

The servomotor must be installed on a site that is free of aggressive and conductive materials. The EMC shielding and earthing must be done according to the specified installation instructions for the servo amplifier used. The motor leads must be connected as close as possible to the servo amplifier. The device has a phase-to-phase winding inductance of 32mH and a phase-to-phase winding resistance of 1.91 Ohms. The shielded motor cables have a cross-sectional area of 4 x 2.5mm². The motor leads are ideal for trailing. They have a lifetime of one million bending cycles and a capacitance of less than 150pF/m. The BH-622-B-99-270 servomotor can be sent to any address across the globe through our reliable shipping team.

The synchronous motor has a polyurethane sheathing and a polyteraphtalate core insulation. The device must be cooled to a temperature of less than 40°C after use, before handling it. The unit weighs 16.8kg. This product also has a thermal time constant of 28min. The motor housing must be earthed to a protective earth busbar safely inside the switch cabinet.  This product is a good choice for high dynamics requirements. The servomotor experiences high radial force if it is driven through toothed belts or pinions. The motor windings come integrated with thermal contact.
