The B-204-B-11 is manufactured by Kollmorgen as a part of their Goldline B/BH Motor Series. These motors feature a max BUS of 320 and a max stall tc of 61.1 lb-in. As a low inertia motor, it features a max speed of 2800 RPM and a max rated power of .82 kW.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

Kollmorgen’s Goldline series of brushless servo motors offers optimum performance. It features a wide range of servos, all dynamic in nature, that can be used on a variety of applications. This series features a rare-earth magnet known as neodymium-iron-boron, which delivers high energy levels at low voltages. Besides the internal magnet, the thermal design of the motors offers high continuous torque, power, and speed. When combined with SERVOSTAR certified amplifiers, Goldline motors offer great performance. There are three categories in Goldline series: low-inertia motors, medium-inertia motors, and explosion-proof motors. Low-inertia B series motors are lightweight and highly efficient.

The B-204-B-11 brushless servo motor has a weight of 6.2 kilograms. Its rated power is 1.6 kW while it can reach up to 3600 RPMs. The continuous stall torque of the servo motor is 4.47 Nm at 40 degrees Celsius and the maximum torque is 13.8 Nm. This servo motor has rotor inertia of 0.000179 kilograms-squared meters, which is exceptionally low. This ensures rapid acceleration and deceleration of the synchronous motor. The B-204-B-11 brushless servomotor is compatible with the SR10 servo amplifier.

The B-204-B-11 servomotor has a motor frame of 20 and a rotor length of 4 stacks. There are two flying lead connectors at the top. This servo motor has a dimension of 92mm x 92mm x 275.3mm. The shaft of the motor is 30mm long and has a 14mm diameter. To add durability there is a shaft extension at the rear side as well. This brushless servo by Kollmorgen offers IP65 sealing to protect its components. It features a built-in thermostat, while the H-class insulation material ensures smooth performance under high temperatures.

  • B204-B11
  • B-2O4-B-11
  • B-24-B-11

B-204-B-11 Technical Specifications

:
Max BUS : 320
Max Rated Power: .82 kW
Max Speed: 2800 RPM
Max Stall Tc : 61.1 lb-in
Max Tp: 176.1 lb-in
