Product Description
The EP3624-1434-7-56BC-CU is an EP series explosion-proof DC motor from Kollmorgen with SCR rating. The motor has a 1750RPM rotating speed and features Class H insulation. The unit comes with a NEMA 56C face. The TENV non-vented enclosure comes along with a removable base. It has 52A peak current rating and 2.6A continuous current rating. The permanent magnets generate light, small, and efficient magnetic fields and have an anti-cogging property for operating the motor smoothly at low speed.
The large sealed bearings are of standard type. The armature of the motor encompasses polyester impregnation for mechanical and electrical integrity. The motor has a 1/4HP power rating and 4.07lbs-in/A torque constant. It is UL Recognized and CSA Certified. The permanent magnet motor weighs 23 LBS. The unit is used in various industries like robotics, medical imaging, aerospace, defense, etc. and is backed by superior quality and rugged construction.
The washdown duty motor comes with brush springs that are equipped with field-replaceable brushes. These brush springs provide constant force and have a long life. The motor has a conduit box for easy termination, as well as a fused and rugged commutator. The device has the capability of dynamic braking without demagnetization. The unit comes in 10.38 inches size. It has 9lbs-in continuous torque, 2.63 ohms resistance and 10.5mH inductance. The hybrid motor which comes with a one-year warranty can be delivered to any part of the world using our delivery partners who have a wide logistics network. The manufacturer also offers several other types of motors such as servomotors and stepper motors, apart from motion controllers, amplifiers and drives.
