AKM12C-ANCNR-00

Name: AKM12C-ANCNR-00
Brand: Kollmorgen
Price: 474 USD
Availability: InStock
Rating: 4.5 (32 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships 3-5 Days

Current response time:

4 Minutes 12 Seconds

The AKM12C-ANCNR-00 Is manufactured by Kollmorgen and features a max BUS of 320 and max Tp of 1.46 Nm. The AKM series also featured a max rated force of 8000 and max rated power of .30 Kw.

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

The AKM12C-ANCNR-00 is a synchronous servomotor from Kollmorgen in the AKM series which delivers high and dynamic performance. The motor is fitted with a 40mm flange and has a rotor length of 2 as well as a winding type of C. The connectors of the unit must not be unplugged when the motor is in use. The device operates at a temperature range of 5°C and 40°C. If the motor is mounted vertically with the shaft end upwards, care must be taken to ensure that liquids do not enter the upper bearing. The unit features Class F insulation. The device is available with a warranty period of one year.

The motor must be used only with a SERVOSTAR digital servo amplifier under torque or speed control. The device should never have a direct connection to the mains supply. The motor windings are integrated with a thermal contact and the rotor is housed with permanent rare earth magnets. The unit has a peak current rating of 6.06A and a peak torque rating of 1.08A. The lightweight motor weighs 0.49kg. The rotor has a moment of inertia of 0.031kgcm². The design of the flange is based on IEC specifications. The device is fitted with a smooth shaft and a 0.5m shielded cable with IP 65 connectors.

The servomotor must be checked for bearing noise after every 2500 hours of operation. The operation should be stopped when there is such a noise and the bearings must be replaced. The motor may not rotate due to instances such as non-enabling of the servo amplifier, mechanical block in the drive, or wrong sequence of motor phases. The motor must be disposed only through a certified disposal company. The synchronous device can be shipped anywhere in the world through our delivery partners.

AKM12C-ANCNR-00 Technical Specifications

Frame Size:	AKM1
Number of pole pairs:	3
Maximum rated DC bus Voltage :	320V
Peak current:	6.06Arms
Maximum Mechanical speed:	8000rpm
Continous torque at a winding temperature of 1000C:	0.310Nm
Weight:	0.49kg
Inertia :	0.031kg-cm2
Torque constant:	0.207Nm/A
Back EMF constant:	13.3V/Krpm

Frequently Asked Questions about AKM12C-ANCNR-00

Q: What is the service life of the ball bearings in the AKM12C-ANCNR-00?

A: Ball bearings present in the AKM12C-ANCNR-00 have a service life of about 20,000 hours. This service life can reduced is the the output shaft is overlaoded during operation.

Q: What servo drive series is suitable for the control of the AKM12C-ANCNR-00?

A: The AKD servo drive is designed specifically for the AKM motor series. The connection of the motor to third part drive is not recommended as this can lead to unexpected motor movement.

Q: Is the AKM12C-ANCNR-00 suitable for operation in harsh conditions?

A: The operation of this industrial motor in harsh environmental conditions is permissible. The motor housing meets the IP65 protection and can effectively prevent the penetration of the motor from both solid and liquid external interference.

Q: Can the AKM12C-ANCNR-00 be used in food processing operation?

A: The AKM12C-ANCNR-00 is covered with a black varnish and is not suitable for food processing operations since the highest degree of hygine is required. However the customers can order for variants that are designed specifically for food processing.

Q: What type of industrial application is the AKM12C-ANCNR-00 suitable for?

A: This industrial motor is designed for industrial machines that require a high torque over a broad speed range. Example of these industrial machines includes textile machines, packaging machines, printing machines, and lots more.
