AKD-P02407-NBEC-0000

Name: AKD-P02407-NBEC-0000
Brand: Kollmorgen
Price: 145 USD
Availability: InStock
Rating: 4.3 (19 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships in 3 Days

Call for Expedited Shipping and Product Condition Options

The AKD-P02407-NBEC-0000 is manufactured by Kollmorgen as part of the AKD Servo Drive Series. These drives are fast, and flexible drives with features such as a drive continous output power of 16000 Watts and a rated supply voltage of 240/480 V. As well as, Rated output current of 24 A and a peak output current of 48 A. AKD drives offer the greatest output in a compact body.

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

Kollmorgen servo drives in the AKD series have revolutionized how industrial servo motors are controlled. AKD drives are specially designed to be used with synchronous servo motors that use closed-loop control of speed, torque, and or position. Kollmorgen drives are meant to be mounted and operated inside a drive to avoid unintended access and prevent injury to personnel. For the power supply, Kollmorgen AKD drives can be operated with a single phase or a three phase power source supplying between 120 Volts AC and 480 Volts AC. Note that the power supply should not have over 200 kilo Amperes symmetrical current.

The AKD-P02407-NBEC-0000 is a servo drive designed and manufactured by Kollmorgen. It supports an input voltage of between 240 Volts AC and 480 Volts AC supplied by a three phase power source. Being a standard drive, the AKD-P02407-NBEC-0000 is not designed to be used in industrial environments with electrically conductive acids, corrosive solutions, ships, explosive areas, or offshore applications. With a storage temperature rating of between -25 degrees Celsius and +55 degrees Celsius, the drive can be stored within the factory premises without requiring any special storage conditions.

The Kollmorgen AKD-P02407-NBEC-0000 saves on maintenance costs because it does not require maintenance. Note that to avoid voiding the warranty, the drive should only be opened and cleaned by Kollmorgen. The drive is easy to clean on the outside because it only requires a clean dry brush eliminating the need for expensive cleaning products and or procedures. By being listed by Underwriters Laboratories and conforming to the United States standards and Canadian National standards, the AKD-P02407-NBEC-0000 adheres to global standards preparing it for international usage. The AKD-P02407-NBEC-0000 has integrated EMC filters.

AKD-P02407-NBEC-0000 Technical Specifications

Control Logic, Supply Voltage:	24 V
Cooling:	Forced ventilation via built-in fan
Protection class :	IP20
Weight:	11.7Kg
Rated Supply Voltage:	3 x 240 V to 480 V
Rated Supply Input frequency:	50 Hz to 400 Hz
Rated input power for S1 Operation:	15.2kVA
Continuous Output Current:	24Arms
Thermal Dessipation at rated current:	237 W
Noise Emission(low speed/high speed fan):	48/58dB

Frequently Asked Questions about AKD-P02407-NBEC-0000

Q: What type of industrial motor is the AKD-P02407-NBEC-0000 designed for?

A: The AKD-P02407-NBEC-0000 is designed exclusively for driving synchronous servo motors. The drive reliably carries out the closed loop control of torque speed and position of synchornous motors.

Q: Is the AKD-P02407-NBEC-0000 suitable for for group installation with other drives?

A: The AKD-P02407-NBEC-0000 has not be evaluated by Kollmorgen for group installation. It is the responsibility of the user to review and evaluate group installation of the drive for circuit protection, fuse protection and input current rating.

Q: What does do I need to properly install the AKD-P02407-NBEC-0000 drive?

A: The proper installation of the AKD-P02407-NBEC-0000 requires a 3mm T-handle Allen Key, a No.2 Philips head Screwdriver, a small slotted screwdriver, and and M4 hexagon socket-cap screws. Instructions on how to properly install the AKD-P02407-NBEC-0000 are stated in the manual supplied with the drive.

Q: How can the electrical noise generated by the AKD-P02407-NBEC-0000 be reduced.

A: First, Ensure you use Kollmorgen cables for your connections, also the cables between the AKD-P02407-NBEC-0000and filters or external regen resistors must be shielded. Finally, use differential inputs for analog signals.

Q: How can the operation get information from the AKD-P02407-NBEC-0000?

A: The AKD-P02407-NBEC-0000 features a seven segment light emitting diode through which indicates the operational status of the drive after the 24V supply is swiched on. The can also be connected to a PC or PAC to get information.
