AKD-P00606-NBCC-0000

Name: AKD-P00606-NBCC-0000
Brand: Kollmorgen
Price: 444 USD
Availability: InStock
Rating: 4.5 (34 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships in 3 Days

Call for Expedited Shipping and Product Condition Options

The AKD-P00606-NBCC-0000 is manufactured by Kollmorgen as part of the AKD Servo Drive Series. These drives are fast, and flexible drives with features such as a drive continous output power of 2000 Watts and a rated supply voltage of 120/240 V. As well as, Rated output current of 6 A and a peak output current of 18 A. AKD drives offer the greatest output in a compact body.

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

Kollmorgen servo drives in the AKD series are flexible, feature-rich, and designed to support high-performance industrial applications. With their full-frequency, wizard-based autotuning functionality, these drives can be used to provide precise motor positioning even when deployed in a demanding environment. Kollmorgen AKD drives support option cards that can be used to enhance their processing power or increase the number of inputs and outputs. To improve the drives’ dependability, they monitor the temperature, voltage and current. Apart from added dependability, monitoring the drives’ voltage, current, and temperature allows for timely troubleshooting.

The Kollmorgen AKD-P00606-NBCC-0000 is an AKD servo drive that has a compact design, an industry-leading power density, and is robust. It has an international protection rating of IP 20 meaning that it has to be mounted and operated inside a control cabinet that can provide protection against liquids and solids exceeding the size of a human finger. To help in providing optimum performance, the drive shuts down if the temperature inside the control cabinet exceeds 40 degrees Celsius making the drive to fault since the motor has no torque. The AKD-P00606-NBCC-0000 has a current rating of 6 ARMS and belongs to the AKD-P subseries of the wider Kollmorgen AKD series.

The AKD-P00606-NBCC-0000 has standard USA customizations and supports both EtherCAT and CANopen connectivity options. Because it is impossible to use the two connectivity interfaces at the same time, the drive features the ‘DRV.TYPE’ software parameter to select either of the two connectivity options. With an input voltage rating of between 120 and 240 Volts AC supplied either by a single or a three phase power source, the AKD-P00606-NBCC-0000 smoothly fits into the existing industrial power supply network.

AKD-P00606-NBCC-0000 Technical Specifications

Control Logic, Supply Voltage:	24 V
Rated input power for S1 operation:	2.38kVA
Protection Class:	IP20
Cooling Type:	Forced Ventilation
Weight :	1.7kg
Current Rating:	6Arms
Volatage Rating:	120/240Vac
Switching frequency of output stage:	10kHz
Connectivity Options:	Ethercat & CANopen
Rated supply input frequency:	50 to 400Hz

Frequently Asked Questions about AKD-P00606-NBCC-0000

Q: Does the AKD-P00606-NBCC-0000 generate a lot of noise during operation?

A: The AKD-P00606-NBCC-0000 is an environmentally friendly device that generates a noise of about 39dB. Most of the noise generated by the drive controller is generated by the interanal air blower present in the controller housing.

Q: is it AKD-P00606-NBCC-0000 delivered with a grounding plate?

A: The grounding plate is part of the standard accessoires supplied with the AKD-P00606-NBCC-0000 drive controller. Other accessories supplied with the controller include mating connectors, a printed copy of the AKD safety guide and a DVD containing the AKD installation manual.

Q: Can the electrical connections of the AKD-P00606-NBCC-0000 be done with third party cables?

A: The use of third party cables for the electrical connections of the AKD-P00606-NBCC-0000 is not recommeded. Customers are advice to make separate orders for standardized cables as this will gurantee saftey and preserve the warranty covering the controller.

Q: How can operators minimize the leakage current generated when the AKD-P00606-NBCC-0000 is in operation.

A: The leakage current generated when the AKD-P00606-NBCC-0000 is in operation can be minimized through the use of low capacity cables and the reduction of the length of the engine cables. The drive should also be properly grounded.

Q: In what environmental conditions should the AKD-P00606-NBCC-0000 be operated?

A: The AKD-P00606-NBCC-0000 should always be operated in a contol cabinet that meet at least the IP54 protection class. The environment when the control cabinet is operated should be dry, cool and free of dust and other particles.
