Home Kollmorgen AKD Servo Drive Series AKD-P00307-NBCC-I000

AKD-P00307-NBCC-I000

Name: AKD-P00307-NBCC-I000
Brand: Kollmorgen
Price: 282 USD
Availability: InStock
Rating: 4.7 (9 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships 3-5 Days

Call for Expedited Shipping and Product Condition Options

The AKD-P00307-NBCC-I000 is manufactured by Kollmorgen as part of the AKD Servo Drive Series. These drives are fast, and flexible drives with features such as a drive continous output power of 2000 Watts and a rated supply voltage of 240/480 V. As well as, Rated output current of 3 A and a peak output current of 9 A. AKD drives offer the greatest output in a compact body.

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

Kollmorgen produces drives that are flexible and easy to use. They use ethernet-based communication functions that help them integrate into any application. The AKD series offers excellent performance options for small devices to increase their service life. Kollmorgen has a workbench graphical user interface for easy set-up and processing.

This AKD Servo Drive Amplifier consists of EtherCAT and CANopen Fieldbus connectors. EtherCAT has an X5 and X6 motion bus interface, and CANopen has an X12 and X13 connectors. The AKD-P00307-NBCC-I000 has an IP20 enclosure protective rating to withstand essential touch and rudimentary dust protection. The EtherCAT Fieldbus has RJ45 connectors, and the CAN-Bus system has an RJ12 connector with an enclose wire jumper. The input voltage rating of this drive is 400-480 volts DC, and the output voltage varies from 0-480 volts DC. This model drive supports both types of Fieldbus connectors within one standard software and runs on any one of the Fieldbus connectors for connecting and communicating with the system.

The weight of this particular drive is 4.3 kgs. The input frequency varies from 50-60 Hz, and the output frequency varies from 0-800 Hz. This AKD drive has a connection to the EtherCAT network via RJ45 connectors. The input and output rated powers are 2000 kW and 14 kW. It has 3-phase input and output systems with three arms and works with a current-rating of 2.24 KVA. The input and output rated current for this drive are 2.7 and 3 Amperes. This drive is customized based on the standard international safety specifications. The storage temperature for this drive ranges from –25 to +45 degrees Celsius.

AKD-P00307-NBCC-I000 Technical Specifications

Control Logic, Supply Voltage:	24 V
Position loop bandwidth max:	1 to 250 Hz
Continous power:	2000 W
Control logic, supply voltage:	240/480 V
Rated Output Current:	3 Amp
Peak time:	5 s
Current loop bandwidth max.:	2.5 to 4 kHz
Velocity loop bandwidth max.:	0 to 8000 Hz
Update rate:	1.5 MHz
Weight:	2.7 kg

Frequently Asked Questions about AKD-P00307-NBCC-I000

Q: Is the AKD-P00307-NBCC-I000 suitable for multiple types of drive control systems?

A: Yes, the AKD-P00307-NBCC-I000 can be used for various types of automation applications because of its ability to command multiple motions. With multi-DOF capability and a closed loop position control system, the drive is suitable for multiple types of drive control applications.

Q: How often should the system's pulse inhibitor be checked?

A: To ensure smooth operation, the system's pulse inhibtor shoud be check every 8 hours.

Q: What temperature conditions are suitable for using this motor?

A: The AKD-P00307-NBCC-I000's optimum performance can be ensures when it is operating within a temperature range of 0 to 40 degrees celsius.

Q: What type of connectivity options are available with the AKD-P00307-NBCC-I000?

A: The AKD-P00307-NBCC-I000 is provided with the CAN open system that comes with the RJ25 type fieldbus connectors for standardized communication.

Q: Can the AKD-P00307-NBCC-I000 handle different voltage conditions?

A: Certainly, the AKD-P00307-NBCC-I000 is compatible with voltages in the range of 0 to 480 V DC because of its verstaile DC link voltage.

Internal Product Review

‘‘The AKD-P00307-NBCC-I000's flexible design allows its use in various applications. The system is also useful because of its various connectivity options such as CANopen. Overall, the AKD-P00307-NBCC-I000 is a vaulable addition to any automation setup.’’
