AKD-P00306-NBEC-0000

Name: AKD-P00306-NBEC-0000
Brand: Kollmorgen
Price: 177 USD
Availability: InStock
Rating: 4.4 (8 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships Today

Call for Expedited Shipping and Product Condition Options

The AKD-P00306-NBEC-0000 is a high-performance position indexer drive by Kollmorgen, featuring EtherCAT compatibility, Safe Torque Off, and real-time data acquisition for precise motor control.

Request a Quote Request Repair

Description
Revisions
Specs
FAQ

Product Description

The AKD-P00306-NBEC-0000 is a high-performance position indexer drive by Kollmorgen. It operates with both single-phase (120/240 V) and three-phase (120/240 V) input supply voltages with a 10% tolerance. The drive's current consumption ranges from 2.3 to 5 A, depending on the supply voltage. It delivers continuous output power of 625 VA for 1x240 V and 3x120 V, and 312.5 VA for 1x120 V and 3x240 V, with a continuous current output of 3 A for both single and three-phase configurations.

The AKD-P00306-NBEC-0000 features a DC bus link voltage between 170 to 340 V and is compatible with EtherCAT connectivity. It includes a built-in fan and can be installed in a vertical position. The drive's two-digit seven-segment LED display provides essential status information. The Safe Torque Off (STO) feature ensures operational safety. This AKD drive supports synchronous, linear, and induction motors, making it versatile for various applications. It is suitable for automotive, textile machinery, medical equipment, CNC machinery, and industrial robotics. The precise control ensures accurate and reliable performance in demanding environments. With a weight of 1.7 kg, the AKD-P00306-NBEC-0000 operates under ambient conditions ranging from 0 to 40 degrees Celsius. It is rated for up to 1000 MSL max installation and provides IP 20 protection. Real-time data on current, temperature, and over-voltage helps prevent issues, enhancing reliability.

The drive?s fast data acquisition, with a maximum current loop bandwidth of 2.5 to 4 kHz, and a real-time update rate of 1.5 MHz when connected via Ethernet, ensures efficient performance. Available at Wake Industrial, it comes with a one-year replacement warranty, providing peace of mind for our users. Order this position indexer drive today and get it delivered to your business address.

AKD-P00306-NBEC-0000 Technical Specifications

Continuous Output Current:	3A
DC-bus link voltage:	170 - 340 V
Supply voltage:	120V/240V (both single and 3-phase)
Weight (standard width):	1.7kg
Height(without connectors):	168mm
Height(with connectors):	200mm
Communication Protocols:	EtherCAT
Update rate:	1.5MHz
Velocity loop bandwidth:	0 to 1000 Hz
Position loop bandwidth (max):	1 to 250 Hz

Frequently Asked Questions about AKD-P00306-NBEC-0000

Q: What communication protocols are supported by the AKD-P00306-NBEC-0000?

A: The AKD-P00306-NBEC-0000 servo motor drive servo drives support EtherCAT communication protocols. However, various options are also available including PROFINET, EtherNet/IP, Modbus TCP, and SERCOS.

Q: What software tools are available for programming and configuring the AKD-P00306-NBEC-0000?

A: The AKD-P00306-NBEC-0000 servo motor drive can be programmed and configured using the Kollmorgen WorkBench GUI software, which provides features like auto-tuning, performance optimization, and easy sharing of program plots and parameter settings.

Q: How do I perform an initial drive test on an AKD-P00306-NBEC-0000?

A: To perform an initial drive test on an AKD-P00306-NBEC-0000 servo motor drive servo drive, unpack and mount the drive, wire it with the minimum connections, set the IP address, confirm the connections, install and start the KAS IDE software.

Q: How do I set up the IP address on an AKD-P00306-NBEC-0000 servo drive?

A: To set the IP address on an AKD-P00306-NBEC-0000 servo motor drive, use the WorkBench software's "Set IP Address" function under the "Tools" menu.

Q: What feedback devices are compatible with the AKD-P00306-NBEC-0000?

A: The AKD-P00306-NBEC-0000 servo motor drive support a wide range of feedback devices including resolver, SFD, SFD3, BiSS, EnDat 2.1, EnDat 2.2, and Hiperface.

Internal Product Review

‘‘Kollmorgen's AKD-P00306-NBEC-0000 position indexer drive ensures precise control with a current loop bandwidth of 2.5 to 4 kHz and real-time updates at 1.5 MHz. It's essential for automotive, medical equipment, and CNC machinery, providing reliable performance with advanced safety features.’’
