The 16.F5.CDE-340A servo motor by KEB Automation offers 15kW power and 43A output current. It features open and closed-loop speed control for high-precision operation in Industrial automation tasks.

Email

Phone

Part Number

+Add a message

Website

Preparing your secure checkout page...

Product Description

The 16.F5.CDE-340A is an advanced servo motor used in industrial automation. It is developed by KEB which is known for manufacturing and supplying motion control and automation technology equipment. This motor is highly versatile to be controlled and operated with total reliability in power demanding applications. It is a part of COMBIVERT F5 series with enhanced applications of speed variation and intricate processes automation.

This 16.F5.CDE-340A servo motor is operated at an electrical frequency of 50/60 Hz and has a power output of 15 kW with a three-phased (3ph) system. This means it can effectively undergo open-loop and closed-loop speed control making it adaptable to various situations. It has 43A of rated input current and 33A of rated output current. This provides significant power for tasks involving high torque and accurate operation. The cross-section of the motor cable diameter is 10mm² to provide maximum power supply and minimal signal attenuation. The 16.F5.CDE-340A servo motor is designed to perform on a wide range of temperatures from 10°C to 60°C which meet the multiple needs of different environments. It is part of a series that is famous for modularity with programmable logic controllers (PLCs) in manufacturing and production line automation. Flexibility is observed in this servo motor regarding the type of input/output, whether it is digital or analog.

The 16.F5.CDE-340A servo motor is placed in an enclosure with intermediate protection of IP20. This protects the motor from dust accumulation and minor contact. The motor can work with its maximum heat sink temperature of 90°C for the best thermal operation. It also features over-voltage and over-current protection to the motor. It safeguards connected equipment from electrical disturbances. The combination of these features makes it a good choice to use for precise control and long-term reliability.

16.F5.CDE-340A Technical Specifications

Frequency:	50/60HZ
Output rated current:	33 A
Motor cable cross-section:	10 mm2
Operating Temperature:	-10°C to 60°C
Power Rating:	15kW
Phase:	3ph
Speed Control:	Open or Closed Loops
Product Range:	COMBIVERT F5
Type:	Programmable Logic Controller (PLC)
Protection Rating:	IP20
Max. heat sink temperature :	90°C
Input rated current:	43 A

Frequently Asked Questions about 16.F5.CDE-340A

Q: How does the 16.F5.CDE-340A ensure efficient power transmission?

A: The 16.F5.CDE-340A uses a 10 mm² motor cable cross-section, minimizing signal loss and enhancing power efficiency. This ensures reliable and stable motor operation in Industrial automation systems.

Q: What is the benefit of over-voltage protection?

A: Over-voltage protection in the 16.F5.CDE-340A ensures the motor remains safe from voltage spikes, preventing damage to both the motor and the connected systems. It improves reliability during power fluctuations.

Q: Why is the motor rated for such a high operating temperature?

A: The motor operates efficiently at temperatures between -10°C to 60°C, providing flexibility in varied environments. Its robust design helps it perform reliably across a wide range of Industrial conditions.

Q: Why is a maximum heat sink temperature of 90°C specified?

A: The 90°C heat sink temperature in the 16.F5.CDE-340A ensures optimal cooling during operation, preventing overheating and maintaining performance stability during extended use.

Q: What are the advantages of the 16.F5.CDE-340A motor’s 15kW power rating?

A: The 15kW power rating of the 16.F5.CDE-340A provides sufficient power for demanding applications requiring high torque and precision. This makes it ideal for heavy-duty automation tasks.
