VLT3016

Product Description

VLT3016 is a popular frequency converter. The product is available with numerous useful functions, enhancing its usability in a wide range of applications. The control principle states that the frequency converter rectifies the ac voltage to DC. It works again to convert this DC voltage to AC again which is with variable amplitude and also frequency. This variable voltage and also the frequency supplying the motor makes it possible to have speed control perfectly and that through with three phase asynchronous motors.

Some features of the product are:

The frequency converter is available with a constant load of Nominal [HP] – 15. Its output current is continuous Amps - 24.0. Its maximum motor size (HP) is 20. Its maximum wire size (AWG) is 6. It is available with a maximum motor cable length which is of 1000 feet when unshielded. It is available with a built in thermal protection which is electronic. It features thermistor acc. to DIN44081. Its maximum input is marked at 23.4 while its current is 30. Its maximum prefuses are 6. Its ramp times is marked at 0.1 to 3600

Other features include the following:

• Its Intermittent Amps (60 s) is marked at 38.4
• It has an available output voltage[%] - 0-100, of AC line voltage
• It is available with an Output frequency[Hz]0-120 or 0-500;  This is programmable
• The rated motor voltage[V] - 380 / 400 / 415
• Output voltage is 0-100, of AC line voltage

The product is available with motor coils which help the product in many ways. With the help of these motor coils, it is possible to use longer motor cables. The cables are completely short-circuit and also earth fault protected. They help in unlimited switching at the output of frequency converter.
