RS51.1-4G-006-L-V1-FW

Name: RS51.1-4G-006-L-V1-FW
Brand: Bosch Rexroth Indramat
Price: 327 USD
Availability: InStock
Rating: 4.5 (13 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911200264

Available

Current response time:

5 Minutes 57 Seconds

The RS51.1-4G-006-L-V1-FW Drive Unit is manufactured by Bosch Rexroth Indramat. This device operates with a nominal connecting voltage of 3 x AC 380-480 V, 6 kVA rated power, and it utilizes a forced air cooling mechanism.

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

The Bosch Rexroth RS51.1-4G-006-L-V1-FW drive control has a design code of 1. The control has a nominal connecting voltage of 3 x 380VAC to 480VAC with a tolerance of +/-10%. This product is supposed to be handled only after reading and understanding its usage instructions and safety regulations. The device operation must take place in the original state without any hardware modification. The unit installation is to be done in accordance with the regulations mentioned in the related documentation. It is used to control and monitor the operation of the manufacturer’s electric motor. The drive control operation has to be done only in the specified configuration and combination of components.

The product must be installed only in the vertical orientation. The device is never intended to be used underwater. The unit is not intended to be used for applications other than intended by the manufacturer. It must be worked on only after ten minutes of switching it OFF so that its capacitors get discharged fully. The control is intended to be operated at a temperature between 0°C and 40°C. The product should not be deployed in medical, nuclear or radioactive applications. This RS51.1-4G-006-L-V1-FW control is available with a year’s Wake Industrial warranty and can be dispatched globally.

The drive control housing has to be permanently grounded as per the connection diagram. The product is likely to portray high voltage because of incorrect connections. This device may have dangerous movements at any point of time during operation because of defective components or incorrect cable connections or wiring of the motor. The vertical axes of this unit have to be secured against falling after the motor has been powered OFF. It must be disconnected from electrical power when it is in storage for a long time. This control utilization must be done only when the application adheres to the national EMC regulations.

RS51.1-4G-006-L-V1-FW Technical Specifications

Cooling Mode:	forced air cooling
Degree of protection :	IP20
Ouput frequency:	0 to 2000Hz
Nominal current :	8A
Nominal connecting Voltage :	380 to 480 V
Brake chopper :	With built-in brake chopper and resistor
Rated power data :	6kVA
Additional function:	24V standby power
Maximum current:	13A
Peak output:	7.5kVA

Frequently Asked Questions about RS51.1-4G-006-L-V1-FW

Q: How does the RS51.1-4G-006-L-V1-FW reduce harmomics during operation?

A: The RS51.1-4G-006-L-V1-FW electrical converter have integrated radio interference suppression filter and a line reactor which operates to reduce harmonics. This integrations allow the drive to completely fulfil the EMC guidelines with refrence to noise immunity and noise emmission.

Q: Can the RS51.1-4G-006-L-V1-FW converter be operated at altitudes that exceed 1000 meters above sea level?

A: The operation of the RS51.1-4G-006-L-V1-FW at heights that exceed 1000 meters above sea level is possible. However when the drive converter is used at these heights, it must be derated in accordance to its operation height.

Q: What is the appropriate mounting position for the RS51.1-4G-006-L-V1-FW in the control cabinet?

A: The RS51.1-4G-006-L-V1-FW must be mounted vertically and unto a flat surface in the control cabinet. Also a mimimum clearance of 100mm must be permitted above and below the drive to allowf ro the easy circulation of air around the cabinet.

Q: What does the Light Emitting Diodes on the RS51.1-4G-006-L-V1-FW indicate?

A: The RS51.1-4G-006-L-V1-FW features three Light Emitting Diodes on the front panel of its housing unit. These diodes provide the operator with information about the current status of the converter.

Q: Is the RS51.1-4G-006-L-V1-FW resistant to industrial vibration?

A: Despite the robust design of the RS51.1-4G-006-L-V1-FW, the converter can only withstand mild vibration. The exposure of the converter to extreme vibration can lead to a damage the device.
