PPC-R22.1N-N-V2-NN-NN-FW

Name: PPC-R22.1N-N-V2-NN-NN-FW
Brand: Bosch Rexroth Indramat
Price: 223 USD
Availability: InStock
Rating: 4.5 (33 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: 1070170150

In-Stock, Ships Today

The PPC-R22.1N-N-V2-NN-NN-FW is a versatile motion controller manufactured by Bosch Rexroth Indramat. There are two serial port interfaces available on the unit. When the device is used as a stand-alone control, it should be installed in the left most slot of an RMB rack. The relative humidity of the product for operation is 5 â€“ 78 % without condensation.

Email

Phone

Part Number

+Add a message

Website

Preparing your secure checkout page...

Product Description

The PPC-R22.1N-N-V2-NN-NN-FW CNC module features an integrated axis processor and a CNC processor system. The axis processor supports the attachment of eight drives through a SERCOS interface. The Bosch Rexroth product features three optional sockets, each of which can be used to fit an axis processor module. The components of this unit may get damaged if it is installed horizontally. The device takes up two module slots in the module rack. The S1 button at the top helps to switch the display. The X15 BT bus connection at the bottom as well as the COM (X16) and PROG (X10) serial interfaces do not have any function. The module weighs 1.3kg.

The product operates at a voltage rating of 24VDC. The device also features a tolerance of -15% / 20% according to EN61131-2 specifications and has a maximum gain of 5%. The top of the unit has a recessed three-pin socket for connecting the buffer battery. The empty battery must be substituted with a new one with the power supply turned on to prevent the loss of SRAM data. The axis processor module is a passive SERCOS interface in a PC/104 format. The boot loader/monitor component of the firmware is essential for the hardware initialization and also for starting the CNC module.

The CNC module communicates with the digital drives through a SERCOS interface that features fiber optic technology. The module must not be operated if it is found to be faulty or damaged. It should be installed and/or started only after reading the documentation provided. There may be high electric voltage if the connections are made incorrectly. The product features a relative humidity of 10% to 95% without condensation. The surface of the device may become very hot during operation and can cause burns if touched. The PPC-R22.1N-N-V2-NN-NN-FW can be shipped worldwide with a warranty of 1-year.

PPC-R22.1N-N-V2-NN-NN-FW Technical Specifications

Permissible Range:	19.2 ... 30 VDC (ripple factor included)
Permissible air pressure during operation:	86 to 106kPa
Firmware:	To be ordered separately
Protection category:	IP20
Weight :	1.3kg
Memory Expansion module:	Not fitted.
Permissible ambinet operating temperature :	0 to 450C
Cooling mode:	forced air cooling
Housing Dimension:	83.7×192×150mm
Rated voltage :	24V
