Home Bosch Rexroth Indramat PPC Series PPC-R01.2N-N-L2-FW

PPC-R01.2N-N-L2-FW

Name: PPC-R01.2N-N-L2-FW
Brand: Bosch Rexroth Indramat
Price: 296 USD
Availability: InStock
Rating: 4.4 (31 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911289826

In-Stock, Ships 3-5 Days

Call for Expedited Shipping and Product Condition Options

The PPC-R01.2N-N-L2-FW motion controller offers real-time SERCOS communication, RS-232 serial ports with configurable baud rates, and DIN rail mounting. Its 24 VDC power input ensures reliable industrial automation performance in a compact design.

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

The PPC-R01.2N-N-L2-FW is a powerful industrial motion controller. It is a product from a well-known company named Bosch Rexroth. It features real-time with flexibility and reliability. The hardware design is extremely compact with features that make it extremely useful in a wide range of applications where control efficiency is very critical. Highlights include a SERCOS interface for real-time communication and an expansion slot for additional fieldbus interfaces.

The PPC-R01.2N-N-L2-FW motion controller is powered by a 24 VDC power supply. It can safely and consistently operate within an allowed range of 19.2 to 30 VDC. The controller achieves conformance to EN61131-2 standards that ensure safe and consistent operation. The SERCOS interface provides the flexibility to talk with up to 40 drives. Due to this, fast and reliable data transfer is possible for high-performance automation tasks. The PPC-R01.2N-N-L2-FW motion controller offers RS-232 ports for serial communication. The baud rate for this protocol can be set between 9600 and 115200 depending upon the requirement. This can be easily done through the software interface from the controller. An expansion slot is available along with an option to connect fieldbus interfaces such as Profibus, Interbus, or Ethernet to add further options to integrate into large systems or complex networks.

The PPC-R01.2N-N-L2-FW is designed to be mounted in an installation location that will provide it with some protection. Its rating is IP20, so the installation location must be akin to mounting in a control cabinet. DIN rails for mounting the controller can be ordered with TS35 mounting brackets, and the mounting of the controller is quite easy. The operating range of the controller is 0 degrees C to 45 degrees C and can be safely stored between -25 degrees C and 70 degrees C. Humidity levels between 5% and 78% can be maintained in operation.

PPC-R01.2N-N-L2-FW Technical Specifications

Power Supply:	24 VDC
Permissible Voltage Range:	19.2 to 30 VDC
SERCOS Interface:	Up to 40 drives
Communication Ports:	RS-232
Protection Rating:	IP20
Mounting:	DIN rail (TS35) with mounting brackets
Operating Temperature Range:	0 degrees C to 45 degrees C
Storage Temperature Range:	-25 degrees C to 70 degrees C
Humidity Range:	5% to 78% (operating)

Frequently Asked Questions about PPC-R01.2N-N-L2-FW

Q: How does the expansion slot benefit PPC-R01.2N-N-L2-FW?

A: The PPC-R01.2N-N-L2-FW's expansion slot allows integration of additional fieldbus interfaces like Profibus, enhancing network flexibility. This feature enables easier system scalability for complex industrial setups.

Q: Why is IP20 protection rating used for PPC-R01.2N-N-L2-FW?

A: The PPC-R01.2N-N-L2-FW's IP20 rating ensures it's suitable for control cabinet installations in protected environments. This protection prevents solid objects but not water ingress.

Q: How does the RS-232 port improve the PPC-R01.2N-N-L2-FW?

A: The RS-232 port in PPC-R01.2N-N-L2-FW allows serial communication for legacy systems. Configurable baud rates support various speeds and data transfer needs.

Q: Why is EN61131-2 compliance important for PPC-R01.2N-N-L2-FW?

A: EN61131-2 compliance ensures the PPC-R01.2N-N-L2-FW meets global safety and performance standards for industrial controllers. This guarantees reliable and safe operation in demanding environments.

Q: How does SERCOS interface optimize PPC-R01.2N-N-L2-FW's performance?

A: The SERCOS interface in PPC-R01.2N-N-L2-FW allows real-time communication with up to 40 drives. It ensures fast, synchronized data exchange for high-precision automation.

Internal Product Review

‘‘The PPC-R01.2N-N-L2-FW motion controller excels in industrial automation, providing seamless SERCOS communication and RS-232 support. With 24 VDC input, IP20 protection, and DIN rail mounting, it ensures robust, reliable performance in protected environments, making it an excellent choice for precision tasks like machining and printing.’’
