NAM 1.1-15

Product Description

Bosch Rexroth products are extensively used in the industrial automation sector. They produce a wide range of high-quality power supply modules, frequency converters, and servo motors for their clients.

The NAM 1.1-15 model is manufactured by Rexroth and it is designed to convert an AC source into an unregulated DC supply. The line connection module can be used with TVD 1.1-15-3 power supply module. The module can take connection through the 3-phase AC 3 × 380 ~ 460V power source and after converting the AC voltage to DC link voltage the power is then transferred to the power supply module which is used to operate the drive module. The line connection module is used where no energy is returned to the supply or where the energy exchange between motor and drive takes place in the DC link. The power supply which is attached to the line connection module can deliver the DC bus continuous power of 15 kW and DC bus peak power of 45 kW. The module helps in delivering the continuous mechanical power of 12 kW by using a communication choke, DC bus choke, and a storage capacitor.

The model NAM 1.1-15 in conjunction with a power supply module produces a complete power supply unit which is a part of a modular INDRAMAT AC Drive System along with a drive and motor. The total dimension of the power supply module is 150 mm width, 390 mm height, and 325 mm depth. The module provides easy installation of the TVD module and the necessary filter components.  A multi-color LED light helps in indicating the status of the module. The module can operate ideally between the ambient temperature ranges of 0 to +40 degree Celsius. This module can be shipped globally with a one-year warranty period from Wake Industrial.
