MSK100B-0400-NN-M1-BG0-NNNN

Product Description

The MSK100B-0400-NN-M1-BG0-NNNN synchronous servomotor comprises a B length code. The Bosch Rexroth motor must have securely locked connectors during operation. This standard-design product features penetration of explosive materials based on the aging of its seals. The device uses an encoder with a 1Vss output signal and 4,096 mechanical rotations. The unit encounters radial as well as axial forces during operation. These forces must never exceed their maximum specified limits. The motor has a B5 frame size according to EN 60034-7 specifications. The product has normal concentricity and alignment tolerance. This device utilizes a plain shaft featuring a cylindrical end and DS M10 centering hole as per DIN 332, Part 2 specifications.

The motor frame size is proportional to its power rating. The unit is cooled through natural convection. Its drive controller positions the motor and controls its speed based on the current motor position. The product supports the attachment of gearbox systems that meet the Ex-protection requirements in compliance with EG 94/9 directives. The device experiences variations in thermal coupling with respect to the machine if transmissions are attached. The unit uses M58 and M23 flange sockets for the power as well as encoder connections respectively.

The product can be connected only in the de-energized state. The cables used to connect the device have to be removed by pulling at the plug. The unit supports a maximum ambient installation elevation of 1000m above sea level. It has a maximum 10m/s² vibration load between frequency ranges of 10Hz to 20,000Hz. The motor has IP 67 protection rating for its connectors with a properly connected cable socket. This product cannot be applied with an extra varnish on its housing when it is used in hazardous areas. The device shaft gets damaged because of intense reversing operation. This MSK100B-0400-NN-M1-BG0-NNNN motor with its warranty for one year is done by reputed freight carriers.
