MSK061C-0600-NN-M2-UP0-RNNN

Product Description

The MSK061C-0600-NN-M2-UP0-RNNN was produced by Bosch Rexroth and belongs to the MSK motor series made for industrial automation activities. This motor remains one of the sought after automation technologies in the world due to its numerous excellent features.

Generally, the MSK motor series can be installed in four different alternative directions (the IM B5, IM V1, IM V3, and IM B36 directions) according to the user's desire. Also, members of MSK motors are usually painted with black varnish by the manufacturer  providing protection against diluted acids and lye, water, seawater, sewage current, mineral oils, organic solvents, and hydraulic oil. However, the paint is unable to offer protection against concentrated acids/lyes. Nevertheless, the user can put another layer of paint with adequate adhesiveness and resistance on the motors, but not thicker than 40 µm.

Like some other members of the MSK motor series, the MSK061C-0600-NN-M2-UP0-RNNN features a multi-turn encoder system for accurate motor positioning and speed monitoring. It also features a standardized IP65 protection system that prevents machine damage due to external contacts, foreign objects and water. For the effective connection of the motor to the main machine, the MSK061C-0600-NN-M2-UP0-RNNN uses shaft with keyway as its output shaft.

The MSK061C-0600-NN-M2-UP0-RNNN makes use of two electric connectors which include the power connector that is responsible for the temperature sensor, and the second is the encoder connector that works with the encoder system.

Other features of the MSK061C-0600-NN-M2-UP0-RNNN include a maximum torque of 32Nm, a maximum current of 34.7A, technical data regulating temperatures of 60K housing temperature and 100K winding temperature, a natural convection cooling system through which heat is dissipated out of the motor system, and an effective thermal overload monitoring that prevents the motor from unrecoverable damage due to heat.

The MSK061C-0600-NN-M2-UP0-RNNN is no doubt an automation technology of high repute and great usability.
