MSK061B-0300-NN-M1-UG0-NNNN

Product Description

The MSK061B-0300-NN-M1-UG0-NNNN is a MSK series motor. It is designed and manufactured by Bosch Rexroth. The motor features a standard housing design. As per the type code the motor frame size is 061, the motor frame length is B and the motor winding code is 0300. The length of the motor housing is 223 millimeters. The plain shaft on the MSK061B-0300-NN-M1-UG0-NNNN motor has a diameter of 19 millimeters. Around 40 millimeters of the motor shaft is outside the motor housing. The seal on the motor shaft protects motor bearings from contaminants such as dust. The motor shaft seal should be inspected periodically and replaced when required. Centering diameter of the MSK061B-0300-NN-M1-UG0-NNNN motor is 95 millimeters. The size of the flange on the motor is 130 millimeters. The motor mounts through holes on the motor flange.

The encoder on the MSK061B-0300-NN-M1-UG0-NNNN is a multiturn absolute encoder that is rated for 128 signal periods. The cooling method for which the motor is designed is natural convection. The permitted temperature for operation is 0 to 40 degrees Celsius. The MSK061B-0300-NN-M1-UG0-NNNN does not include a holding brake. A holding brake can be ordered separately if required. The MSK061B-0300-NN-M1-UG0-NNNN motor gets electrical power from a drive controller. The motor also shares feedback with the drive controller. Separate cables are used for the power and motor feedback. The power and feedback cables connect to designated connectors on the motor housing. Both of these connectors can be rotated 240 degrees in either direction. The moment of inertia of the motor rotor is 0.00044 kg m². The MSK061B-0300-NN-M1-UG0-NNNN motor weighs approximately 5.7 kilograms. The housing of motor belongs to the IP65 category.
