MSK060C-0600-NN-S3-UP1-NNNN

Product Description

The Bosch Rexroth MSK060C-0600-NN-S3-UP1-NNNN is a servo motor. It is intended to be used as a rotary main and servo drive motor. The following are typical fields of application for the motor: machine tools, robotics, metal-forming machines and printing machines. Any connected drive controller must be programmed before startup in order to ensure that the motor executes the functions specific to the particular application. The MSK060C-0600-NN-S3-UP1-NNNN supports several integrated features including encoder, shaft with keyway and sealing ring, holding brake and rotatable connectors. The encoder on the MSK060C-0600-NN-S3-UP1-NNNN is a single turn capacitive encoder with Hiperface support and 16 signal periods. Singleturn encoders provide feedback inside one revolution of the motor shaft. The two connectors on the MSK060C-0600-NN-S3-UP1-NNNN are 240-degree rotatable. The motor holding brake is rated for 20 Nm holding torque.

The MSK060C-0600-NN-S3-UP1-NNNN motor has a standard housing design. The supported cooling method is natural convection. The continuous torque at standstill is 8 Nm. The continuous current at standstill is 9.5 Amps. The peak motor torque is 24 Nm and the peak motor current is 38 Amps. The thermal time constant of the MSK060C-0600-NN-S3-UP1-NNNN motor is 14 minutes. The maximum rated speed of the motor is 6000 RPM. The motor weight, including the weight of the holding brake, is 9.2 kilograms. The MSK060C-0600-NN-S3-UP1-NNNN performs with rated data at 0 to 40 degrees Celsius. The motor performs with derated data outside this temperature range. Use of the motor outside recommended ambient conditions should be avoided. Use of the motor for unapproved applications should be avoided. The motor housing is IP65 rated and provides total dust protection. The motor and associated equipment should be installed by trained personnel.
