MSK060C-0300-NN-M1-BP1-NNNN

Product Description

With years of experience in designing the world’s most efficient drive and motion control products, Bosch Rexroth can be relied on for only the best automation product delivery. These include gearboxes, frequency converters, and servo motors like those in the MSK series. They are powerful compact motors in a range of frame sizes, speeds, and torques, used as rotary main and servo drive motors in diverse applications. Some of these applications are machine tools, robotics, printing and paper processing machines, food processing and packaging machines, and metal forming machines.

The MSK060C-0300-NN-M1-BP1-NNNN is a servo motor in the MSK series of the IndraDyn S group by Bosch Rexroth. It can reach a maximum speed of 4,900 revolutions per minute and has a maximum torque of 24.0Nm. The maximum current for its operation is 19.2A, while its rotor has a moment of inertia of 0.000080kgm². This motor is equipped with an integrated optical multiturn absolute encoder with a Hiperface interface and 128 increments for speed and position control. The system accuracy of the encoder is +/-80 angular seconds, and it permits the recording of the absolute, indirect position within 4,096 mechanical motor rotations. It also features a data memory where information read by its drive controller can be stored.

The cooling of the MSK060C-0300-NN-M1-BP1-NNNN is by natural convection, where the heat produced by the motor is dissipated into the ambient air and conducted onto the machine construction. Its electrically released holding brake has a holding torque of 10Nm and holds the axis when the machine is de-energized. It uses an output shaft with a key according to DIN 6885-1 and a sealing ring for connecting machine elements to be driven.
