MKD112B-048-GG1-AN

Product Description

The Bosch Rexroth MKD112B-048-GG1-AN is a synchronous motor which is part of MKD product line. Together with Rexroth drive controllers, MKD motors can be used for a wide range of industrial applications including handling, automation, paper industry and machine tools. As per the type code for MKD, the motor size for the MKD112B-048-GG1-AN is 112 which corresponds to flange size of 192 millimeters and centering diameter of 130 millimeters. Motor length for the MKD112B-048-GG1-AN is B as per the type code which corresponds to 28 Nm continuous torque at standstill. The motor winding code for the MKD112B-048-GG1-AN is 048 as per the type code. Motor winding specifications include 3.1 millihenry inductance and 0.22 Ohms resistance. Four pole pairs are available on the motor. Peak current rating for the motor is 160.2 Amps.

Mechanical specifications for the MKD112B-048-GG1-AN motor include 2800 RPM rated speed and 187 Hertz rated frequency. The rated torque and rated current vary with the overtemperature conditions: at 60K overtemperature the rated torque is 7.7 Nm and the rate current is 6.9 Amps, and at 100K overtemperature the rated torque is 18.1 Nm and the rated current is 16.9 Amps. Power ratings at 60K and 100K overtemperature conditions are 2.7 kilowatts and 6.7 kilowatts respectively. The MKD112B-048-GG1-AN supports resolver feedback and features a plain shaft with key. Also available on the motor is a 22 Nm rated holding brake which weighs 1.1 kilograms and is rated for 0.71 Amps. Power connector on the motor is located on side A. Installation, maintenance and operations of the MKD112B-048-GG1-AN should be performed by trained technical personnel who have read the manufacturer documentation and the safety precautions included in it. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
