MKD112B-024-GG0-LN

Product Description

The MKD112B-024-GG0-LN is a high-performance synchronous MKD motor from Rexroth Indramat. It has a motor length and motor size of B and 112 respectively. The motor length has an actual value of 28 Nm and the motor size indicates a flange size of 192 mm and a Dia. of 130 mm for the centre. This motor is designed with a characteristic speed of 2000 rpm.

The motor winding code designated to the size range of this equipment is 024. This code indicates the characteristic speed and the electric output data of this servo motor. It is designed and intended for use with HDD, DDS, DKC, HDS and DKS servo drives. Like several servo motors from Rexroth, the MKD112B-024-GG0-LN cannot be dismantled or reassembled on site. Under housing overtemperature (60 K) conditions, the approximate environmental temperature is 45 degrees Celsius. The MKD112B-024-GG0-LN has a peak current of 98.5 Amperes, and its torque is 1.43 Nm/A, at a temperature of 20 degrees Celsius. There are four pairs of poles on this equipment, and its winding inductance has a value of 7.6 mH. Its insulation category is F

The MKD112B-024-GG0-LN features an electromagnetic transducer (resolver) feedback system for velocity and position applications. The signals emanating from the resolver feedback is used to control the motor. The design of this equipment affords it a plain driving shaft that comes with a sealing ring and a “DS” threaded end-side centring hole. In addition, this MKD motor does not have an integrated holding brake. The MKD112B-024-GG0-LN comes with its power connector positioned on the left when viewing the driving shaft from the front. This motor offers standard performance when in use. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
