Product Description
The Bosch MKD112A-024-KP0-AN is a synchronous servo motor. It is a permanent magnet motor with electronic commutation. The special magnets used for the construction of the MKD112A-024-KP0-AN enable low inertial mass. MKD motors should be installed and operated according to the recommended guidelines contained in the manufacturer documentation. MKD motors should only be used with accessories which are specified in the manufacturer documentation. Drives which are used for controlling the MKD motors should be configured before startup. MKD motors should only be operated under the environmental conditions specified in the documentation from Bosch. Characteristic motor speed of the MKD112A-024-KP0-AN is 2000 RPM. At this speed and with DC link voltage at 540 Volts, the motor can output continuous torque that is half of the torque at standstill. Rated speed or typical useful speed of the MKD112A-024-KP0-AN is 2500 RPM.
Other useful speeds are possible. The details for the useful speeds can be obtained from the speed-torque curve for the motor. Maximum speed for the MKD112A-024-KP0-AN is 5000 RPM. At 60K overtemperature, the continuous torque at standstill is 15 Nm, the continuous current at standstill is 13.1 Amps, the rated torque is 10.1 Nm, the rated current is 6.2 Amps, the rated voltage is 314 Volts, the rated power is 3.2 kilowatts and the rated frequency is 167 Hertz. At 100K overtemperature, the continuous torque at standstill is 17 Nm, the continuous current at standstill is 15.9 Amps, the rated torque is 13.8 Nm, the rated current is 9.1 Amps, the rated voltage is 332 Volts, the rated power is 4.8 kilowatts and the rated frequency is 167 Hertz. The motor power connector is on side A of the MKD112A-024-KP0-AN. Holding brake is not available on the MKD112A-024-KP0-AN. The motor features a shaft with key per DIN 6885-1 with shaft sealing ring, The MKD112A-024-KP0-AN also supports resolver feedback. This unit can be shipped globally with a one-year warranty period from Wake Industrial.
