Product Description
Bosch Rexroth manufactures this MHP AC motor. In conjunction with POWERDRIVE technology, this motor is in a position to construct a quick-responsive and cost-effective motor solution. The compact motor has a standard power supply unit on a Heidenhain TNC410M, TNC430M, and TNC426M control. This makes it possible for the motor to be used in textile machines, robot, handling machines, and packaging machines. This permanent-magnet excited motor with electronic communication has special magnets that enable a design with lower inertia mass. The basic construction of the MHP115B-024-HP1-BNNNNN motor includes a rotor shaft, motor feedback, optional holding brake, rotor with permanent magnets, and stator with winding.
The MHP115B-024-HP1-BNNNNN comes with great benefits such as high operating reliability, high power data, overload-proof thanks to the motor temperature monitoring feature, high temperature overload capabilities thanks to its favorable heat dissipation, and simple cabling. The motor feedback found in this motor uses an optical measuring principle, 2048 information/revolution resolution, and Sine 1Vss with Z1 track signal form. These features allow for optimal monitor speed and position control. MHP115B-024-HP1-BNNNNN should not be used in the following areas without permission from Rexroth: weapon technologies, airplane and ship technology, burning and furnace facilities, and food processing systems.
Crucial technical data of the motor include a maximum speed of 6000rpm, prime black housing coat, and F insulation class. It weighs about 40kg, has four number of pole pairs, and has a 133 Hz nominal frequency. Ambient conditions include storage temperature of -20 to 80 degrees, operating temperature of 0 to 40 degrees, and a maximum installation elevation of 1000 meters above sea level. Electrical characteristics include 17.9Nm nominal torque, 7.9A nominal current, and 313V nominal voltage.
