Product Description
The MHD115A-058-NP1-BA synchronous motor manufactured by Bosch Rexroth supports both electric commutation and electronic commutation. This motor has permanent magnets made of special magnetic materials in its rotor. The product is associated with a size code of 115. The device may get damaged due to improper storage and transport. This device must be lifted using cranes with lifting sling belts for transport purposes. The unit complies with B05 design in accordance with DIN 42950 specifications. Its flange should be affixed using four M12 size screws with a tightening torque of 87Nm. These screwed connections must be capable of withstanding the forces during operation and the weight of the motor.
The electrical connections of the motor have to be done after its mechanical mounting has been done properly. The product renders maintenance-free operation. This device has a brushless design and grease-lubricated bearings for its entire service lifespan. The unit portrays 7.1Nm rated torque and 133Hz rated frequency when it is cooled by natural convection at 60K. Its plug connectors have to be securely tightened during operation. The motor connection should be done only as per the circuit diagram specified by the machine manufacturer. The device makes use of a power connector with bayonet lock for its power connection.
The motor has an O-ring fitted between its housing and flange socket. The product is intended to be mounted and aligned correctly before its startup. This device is not supposed to be used with a drive controller from other manufacturers. The bearings of the unit are meant to be replaced only by the manufacturer’s service team. Its connection lines must be checked for damage at regular intervals and replaced if needed. This product is widely deployed in machine tools. The device has one-year backup support and it can be shipped to any address based on preference.
