MDD112D-N-030-N2L-130PA0

Product Description

The Bosch MDD112D-N-030-N2L-130PA0 is a digital servo motor. It is deployed with a compatible controller that supplies electrical power and controls motor speed and position. MDD motors can be ordered with the power socket at four locations on the housing. The location has to be specified at the time of ordering. The socket on the MDD112D-N-030-N2L-130PA0 motor is on side A of the housing. MDD motors have either plain shafts or shafts with a keyway. The shaft on the MDD112D-N-030-N2L-130PA0 motor includes a keyway. The function of the keyway is to interlock with the key on the machine to which the motor shaft is connected. This prevents relative rotation and ensures effective torque transfer. MDD112 motors supports optional holding brakes rated for 14 Nm, 40 Nm and 60 Nm holding torque. The MDD112D-N-030-N2L-130PA0 does not feature an optional holding brake.

The centering diameter of the motor is 130 millimeters. The motor supports digital servo feedback. This enables the controller to receive accurate information about motor speed and position so that the controller can adjust its output accordingly. The motor housing design is standard and suited to natural convection and surface cooling. The continuous torque at standstill is 38 Nm with natural convection and 57 Nm with surface cooling. The continuous current at standstill is 60.6 Amps with natural convection and 90.0 Amps with surface cooling. The thermal time constant is 120 minutes with natural convection and 90 minutes with surface cooling. Mass of the motor is approximately 59 kilograms. Nominal speed of the MDD112D-N-030-N2L-130PA0 is 3000 RPM. The protection category of the motor housing is IP65. The motor housing is covered in black prime coat.
