MDD112C-N-030-N2L-130PB0

Product Description

The Bosch Rexroth MDD112C-N-030-N2L-130PB0 is a digital AC servo motor. It is called a servo motor because it supports digital servo feedback. A sensor on the motor, known as an encoder, measures different parameters such as motor speed and torque. This information is continuously sent to the drive controller. The controller continuously compares feedback from the motor with programmed parameter values. Depending on the difference between stored and current parameter values, the controller adjusts its output to bring current values in line with programmed values. As per the type code, the motor frame size is 112, the motor frame length is C and the motor nominal speed rating is 3000 RPM.  The motor housing design is standard. The motor balance class is also standard and complies with DIN VDE 0530 section 15.

The shaft on the MDD112C-N-030-N2L-130PB0 motor includes a keyway. The side B shaft end is standard. A holding brake is not part of the motor package. Optional holding brakes are available and can be ordered separately if required. The motor gets power from the drive controller. The cable carrying the power connects to a socket on side B of the housing. The MDD112C-N-030-N2L-130PB0 is a flange mounted motor. Its flange size is 193 millimeters. Length of the MDD112C-N-030-N2L-130PB0 motor is approximately 462 millimeters. The centering diameter is 130 millimeters. The shaft diameter is 32 millimeters. The portion of the shaft that is outside the housing is approximately 60 millimeters. The MDD112C-N-030-N2L-130PB0 is suited to natural convection and surface cooling. The specified ambient temperature range is 0 to 45 degrees Celsius. The specified elevation range is 0 to 1000 meters. Protection class of the motor housing is IP65.
