MDD112C-N-015-N2M-130PA0

  • Rated 4.3 (16 total ratings)
  • Straightforward Pricing: No Rush Fees, No Credit Card Fees
  • MPN: R911257726
    In-Stock, Ships 3-5 Days

Current response time:

6 Minutes 13 Seconds

The MDD112C-N-015-N2M-130PA0 Servo Motor is manufactured by Bosch Rexroth Indramat. This unit operates with a 1500 Min nominal speed, Digital Servo Feedback with integrated multiturn encoder , a(n) Output Shaft with Keyway, and it is Not Equipped with a blocking brake.

Preparing your secure checkout page...

Warranty
1-year-warranty Wake Industrial Warranty
Shipping
DHL Logo FedEx Logo
UPS Logo Freight Logo
DHL Logo FedEx Logo UPS Logo Freight Logo
Payment
Visa Logo AmEx Logo
Mastercard Logo Wire transfer Logo
Visa Logo AmEx Logo Mastercard Logo Wire transfer Logo
To Speak to a sales representative for pricing and lead time:

Product Description

The MDD112C-N-015-N2M-130PA0 Bosch Rexroth digital AC servomotor houses an output shaft with a keyway that renders a form-fitting transmission of torque. This motor portrays a shaft sealing on the shaft. The product is affected on its A side by thermal deformations in length. This device encounters thermal stress when bevel gear pinions are used. The unit is characterized by standard housing. Its permissible radial force depends on the point where force is applied and the average speed. This motor does not have any blocking brakes. The product is meant to be reseated before use if its storage period exceeds two years.

This device has two M8 tapped holes on its housing. The unit storage and transportation can be done only in the horizontal orientation. Its housing can accommodate two lifting screws as per DIN 580 specifications in the tapped holes. The motor operation, maintenance, and repair must be undertaken only by qualified personnel. This product is characterized by very hot housing during and soon after operation. The device encompasses spigot nuts on its connectors. This unit is constructed using harmless materials that have no negative influence on the environment. This servomotor is available with a year’s Wake Industrial warranty.

The motor is well suited for use in grinding machines. This product uses rare earth material for the permanent magnets embedded in its rotor. The device has an integrated temperature sensor to keep a tab on its motor temperature. This unit has a high level of synchronization. Its shaft is equipped with a keyway. The motor is protected against contact with high voltage with alive or moving parts. This product is not recommended to be cleaned frequently to avoid peeling of the housing coat. The device housing coat can be made thicker by no more than 40µm. This servomotor shipping is done through reputed freight carriers.

  • MDD112CN015N2M130PA0
  • MDD112C N 015 N2M 130PA0
  • mdd112c-n-015-n2m-130pa0

MDD112C-N-015-N2M-130PA0 Technical Specifications

Blocking Brake: Not Equipped
Housing Design : Standard
Motor Feedback: Digital Servo Feedback with integrated multiturn encoder
Nominal Speed: 1500 Min
Output Shaft: Output Shaft with Keyway
