Product Description
The MDD112C-L-020-N2L-130GA1 servomotor delivered by Bosch Rexroth has a winding on either side of its laminated core. This motor is coated with black paint on its housing. The product encompasses a temperature sensor in its windings to prevent overload damage. This device uses a mounting flange with windings for mounting as per Design IM B14. The unit is capable of achieving a non-positive transmission and backlash-free transmission of torque. Its output shaft features a maximum tightening torque of 10 Nm for screws in the threads of the center hole.
This motor supports horizontal and vertical mounting positions. The product-related power and feedback connectors must be ordered separately. This device uses an INS 510 or INS 511 connector as the angle feedback connector. The unit portrays an IP 44 protection class with a blower attachment. Its blower is likely to get detached if the blower is used to lift the motor. This motor has a standard centering diameter of 130 mm for the mounting flange. The product-associated axial force is calculated in terms of its permissible radial force. This device can be identified by the type designation specified on its rating plate. The unit incorporates the power cable as well as the connecting cables for the blocking brake and temperature sensor in its power connection. It depends on the drive controller for the control of its blocking brake.
This motor must be wired according to the terminal diagram of the machine manufacturer. The product uses a protective switch for the connection of the blower. This device has a 12-pin flanged socket for the feedback connection. Its plastic protective covers must be removed only just before assembly. This digital AC servomotor uses an encoder with absolute position detection for feedback.
