Product Description
Bosch Rexroth is a well-known industrial equipment producer. The company manufactures AC servo motors, assembly-line items, geared mechanisms, hydraulic and pneumatic systems, drives, and other components.
The MDD093C-N-060-N2L-110PA0 model housing is developed and built to IP65 standards to protect it from synthetic particle infiltration, moisture, and high voltage contact. The categories of protection are denoted by the acronym IP (International Protection) and two numbers indicating the type of protection. The first number signifies the level of resistance to interaction and penetration by extrinsic objects. The second number shows the degree of protection provided against damaging water penetration. This economical AC servo motor can provide excellent solutions for a variety of applications. The MDD093C AC servo motor features digital servo feedback but no holding brake. The model has a power connector on the motor's side A, as well as a shaft with keyways and a sealing that prevents liquids from entering the motor's housing. This motor has an N balancing class and a thermal time constant of 50 minutes. The centering diameter of the MDD093C AC servo motor is 110mm, and the insulation category is F. Digital AC servo motors are offered in a variety of rotor sizes.
The MDD093C-N-060-N2L-110PA0 model generates a continuous torque of 19.5 Nm by consuming a continuous current of 62.5 A at a standstill position. The model does achieve a maximum rotational speed of 6000 revolutions per minute and it weighs only 22 kg. The model should be operated within specified environmental conditions to achieve its maximum performance (0 to +40 degree of ambient temperature and below 1000 m of mounting height). Wake industrial has this product (MDD093C-N-060-N2L-110PA0) with a 1 year of replacement warranty.
