MDD093C-F-040-N2L-110GB0

Product Description

Bosch Rexroth develops highly dependable and durable industrial automation equipment. Among the company's assets are AC servo motors, linear motors, frequency converters, drive inverters, main spindle motors, power supply modules, and drive controllers.

The MDD093C-F-040-N2L-110GB0 model must be moved within the temperature range of -20 to +80 degrees Celsius and has a centering diameter of 110 mm. Due to the lubricated bearings, the model can generate a handful of maximum potential torque at a maximum nominal speed of 400 revolutions per minute. A power connection is situated on the B-side of the motor, and the sides are identified in the motor's user manual. The MDD093C AC servo motor has digital servo feedback for monitoring speed and position, as well as a casing that employs liquid cooling to distribute heat. According to the motor's user manual, the model should only be run in weatherproofed circumstances and between 0 and +45 degrees Celsius. The MDD093C AC servo motor must be used with the accessories specified in the user manual and may be placed up to 1,000 meters above sea level. This motor is quite dependable owing to its structure and its light weight, which makes it reasonably compact.

The model MDD093C-F-040-N2L-110GB0 is IP65 compliant and features a low moment of inertia and a rapid thermal time constant. The motor is coated black and has an insulation level of F, making it resistant to diluted acids, abrasion, and grit deposits. The coating may peel if the housing is often cleaned with a steam cleaner. The model has an N balancing class and a plain output shaft topped with a sealing ring. This motor (MDD093C-F-040-N2L-110GB0) is covered by a replacement warranty when purchased from Wake Industrial.
