MDD090C-N-020-N2L-110PB0

Name: MDD090C-N-020-N2L-110PB0
Brand: Bosch Rexroth Indramat
Price: 403 USD
Availability: InStock
Rating: 4.3 (7 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911247354

Unused Original Box Pricing Available!

In-Stock, Ships 3-5 Days

Current response time:

6 Minutes 4 Seconds

The servo motor MDD090C-N-020-N2L-110PB0 by Bosch Rexroth delivers precise control with its digital feedback system and has a thermal time constant of 60 minutes. it comes with a shaft featuring keyways.

Preparing your secure checkout page...

Warranty

Wake Industrial Warranty

Shipping

Payment

Surplus

Have a MDD090C-N-020-N2L-110PB0 to sell?

To Speak to a sales representative for pricing and lead time:

Phone

1-888-551-3082

International

1-919-443-0207

sales@wakeindustrial.com

Description
Revisions
Specs
FAQ

Product Description

Bosch Rexroth Indramat is a renowned manufacturer of drive and control technologies. The company offers advanced products such as electric drives, hydraulic systems, and industrial automation solutions. Their MDD series of AC servo motors is known for high precision, reliability and performance in various industrial applications.

This MDD090C-N-020-N2L-110PB0 AC servo motor operates within a permissible ambient temperature range of 0 to 45 degrees C and can be stored between - 20 and + 80 degrees C. It is rated IP65 providing solid protection against dust and water ingress. The motor's insulation classification is "F" that supports heat endurance in demanding environments. The AC servo motor comes with a centering diameter of 110 mm, a shaft with keyways output and a black prime coat housing (RAL 9005). The motor feedback includes a digital servo feedback system that ensures precise control. The servo motor suits diverse operational environments with a maximum installation elevation of 1000 meters above sea level. The motor has a theoretical maximum torque of 72.9 and a standard balance class.

The MDD090C-N-020-N2L-110PB0 AC servo motor has a nominal speed of 2000 RPM and a continuous torque of 10.4 Nm. It offers a continuous current of 12.1 A at a standstill and a maximum current of 72.9 A. This makes it suitable for heavy duty industrial operations. The motor features a moment of inertia of 53 x 10-4 kgm^2 and a torque constant of 0.86 Nm/A. The thermal time constant of the motor is 60 minutes that helps in maintaining stable thermal conditions. The winding resistance at 20 degrees C is 6.8 ohms and the inductance is 6.9 mH. The motor weighs 23 kg adding durability and robust mechanical stability.

MDD090C-N-020-N2L-110PB0 Technical Specifications

Product Type:	AC Servo Motor
Windings Resistance:	1.20 ohms
Housing Design:	Standard
Balance Class:	Standard
Motor Feedback:	Digital Servo Feedback
Rotor Moment of Inertia:	53.0 x 10-4 kgm2
Output Shaft:	Shaft with Keyways
Protection Rating:	IP65
Torque Constant :	0.86 Nm/A
Nominal Speed:	2000 rpm

Frequently Asked Questions about MDD090C-N-020-N2L-110PB0

Q: What are the motor feedback options available in the MDD090C-N-020-N2L-110PB0?

A: The motor includes a digital servo feedback system. This system ensures precise control over operations, enhancing accuracy in industrial applications.

Q: What is the environmental temperature range for the MDD090C-N-020-N2L-110PB0?

A: The permissible ambient operating temperature range is 0 to 45 degrees C. It can also be stored safely between -20 and +80 degrees C, offering flexibility in diverse environments.

Q: What protection does the MDD090C-N-020-N2L-110PB0 offer against external elements?

A: The motor has an IP65 rating, providing solid protection against dust and water ingress. This makes it suitable for harsh industrial environments and ensures longevity.

Q: What are the key mechanical features of the MDD090C-N-020-N2L-110PB0?

A: The motor features a centering diameter of 110 mm and a shaft with keyways output. This design provides enhanced mechanical stability, which is essential for heavy-duty applications.

Q: How does the MDD090C-N-020-N2L-110PB0 manage heat in demanding conditions?

A: The motor's insulation is rated F-class, offering heat endurance. Its thermal time constant of 60 minutes helps maintain stable thermal conditions during continuous operations.

Internal Product Review

‘‘The Bosch Rexroth MDD090C-N-020-N2L-110PB0 AC servo motor excels with its continuous current of 12.1 A and a torque constant of 0.86 Nm/A. The servo motor offers robust thermal stability, a moment of inertia of 53 x 10^-4 kgm^2, and a durable IP65 rated housing.’’
