Product Description
Bosch Rexroth is known for its remarkable contributions in upgrading industrial applications such as handling machines, paper processing and food machines, as well as textile machines. The company offers worldwide shipping with a one-year warranty for its products.
The MAD225C-0100-SA-M2-EQ0-35-N1 model of the IndraDyn A motor generation is cooled via the surface cooling forced by a permanently connected fan unit. The MAD225C asynchronous motor is known for its high continuous ratings and compact dimensions. These motors can be used as servo drives and main rotary driving tasks. The asynchronous motor is optimized for an IP65 degree of protection which keeps it from hazardous environmental conditions. The housing of the motor is prime black coated and insulated with class F category. This motor when used in conjunction with the controllers from the Rexroth IndraDrive series, promises an intelligent drive solution with high power density. The MAD225C asynchronous motor is engineered for open functionality and is equipped with a standard bearing. The permissible ambient temperature for maximum efficiency ranges from 0 to +40 degree Celsius. If needed to store the motor for a longer period, the ambient temperature should be maintained between -20 and +80 degrees Centigrade.
The model MAD225C-0100-SA-M2-EQ0-35-N1 uses a Multi-turn encoder with an absolute positioning system. The encoder promises an accuracy of 2048 increments using EnDat 2.1 interface. This motor is available in standard length and three types of winding, coded as 0050, 0100, and 0150. Customers get an installation guide and usage instructions to experience hassle-free operational life. The motor is designed for flange and foot mounting style. Holding brakes are excluded in this variant. A turn-able terminal box is provided at the A-side of the motor. This model (MAD225C-0100-SA-M2-EQ0-35-N1) allows maintenance during ongoing operation. Order today from Wake Industrial to get it delivered to your business address.
