Product Description
The hmv01.1r-w0018-a-07-nnnn model of the regenerative type power supply unit by Bosch Rexroth is engineered to challenging industrial environment. Bosch shows its commitment to quality and standard with a range of power supply modules available for HMS01 and HMD01 drive controllers. These devices are shipped globally with 01 year warranty by the Wake Industrial.
The HMV01.1R power supply unit falls in series 01 and has a standard design. The device is rated for 18 kW of rated power and IP20 degree of protection. The power supply generates heat during continuous operation which is dissipated with the help of a built-in cooling fan. The nominal DC bus voltage is 700 VDC. The CE conformity and UL listing standard are applied to this model. It is engineered for 42000 A rms short circuit current rating and input voltage of 380 to 480 V from a three-phase AC source. The device operates with an input of 26 A current when operated under 0 to +40 degree Celsius. Above this temperature, data deration may occur up to +55 degree Celsius. The power supply unit delivers an output current of 24 A. This model comes with 13.5 kg mass requiring careful handling and secure mounting. It comes with 175mm width, 262mm depth, and 440mm height.
The hmv01.1r-w0018-a-07-nnnn module is allowed to be mounted in position G1. With its volumetric capacity of 95 cubic meters of air per hour, the device is efficiently kept cool. A minimum distance of 300mm at the top and 130mm at the bottom should be maintained for free air flow. The temperature rise with minimum distances is measured to be 65 K. Customers can identify the model with its type code mentioned on the nameplate.
