HMV01.1E-W0075-A-07-NNNN

Name: HMV01.1E-W0075-A-07-NNNN
Brand: Bosch Rexroth Indramat
Price: 274 USD
Availability: InStock
Rating: 4.6 (17 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911297424

Unused Original Box Pricing Available!

In-Stock, Ships Today

The hmv01.1e-w0075-a-07-nnnn power supply module, designed for Bosch Rexroth's drive controllers, operates with 3-phase AC input of 380-480V, delivering DC output of 700V with a rated current of 75A.

Email

Phone

Part Number

+Add a message

Website

Preparing your secure checkout page...

Product Description

The hmv01.1e-w0075-a-07-nnnn product is a feeding type power supply module manufactured by Bosch Rexroth. This device is designed and developed to power HMS01 and HMD01 drive controllers and comes in various power ranges.

The HMW01.1E power supply module design is based on three sections including interfaces for signal processing, control panel and power connections including control voltage. The module comes with IP20 degree of protection and requires installation in a separate control cabinet to protect it from environmental hazards. With the integrated cooling fan, hot air is blown outside to draw fresh and cool air inside. The device is rated for 75 A of rated current and comes with a choke. The power supply module requires input from a 3 x AC 380 to 480 V power source to deliver DC 700 V. This is a standard variant and comes with a Smart Energy Mode variant. A type plate it attached to its housing mentioning device type, part number, country of manufacture and production week for your ease. The package includes 01 touch guard, 01 joint bar to connect the equipment grounding connector to a neighboring device, connectors for electrical connection points at the device, a standard control panel and instruction manual.

The HMV power supply is limited for use in scope of CSA or UL. This module is manufactured for a short circuit rating of 42000 A rms. The power supply requires an input current of 128 A and provides output current of 173 A rms. This device has 22 kg mass, requiring careful handling during transportation and installation. This model (hmv01.1e-w0075-a-07-nnnn) measures to be 440mm high, 262mm deep, and 250mm wide. The provided capacitance against housing is measured to be 2 x 470 nF.

HMV01.1E-W0075-A-07-NNNN Technical Specifications

Capacitance to housing:	2 x 470 nF
Short-circuit rating:	42,000 A RMS
Weight:	22 kg
Included accessories (mechanical):	Touch guard; joint bar
Included accessories (electrical):	Electrical connectors; control panel
Included accessories (documentation):	Instruction manual
Certification:	CSA/UL (limited use)
Cooling:	Forced convection
Height:	440 mm
Depth:	262 mm
Width:	250 mm
Input current:	128 A
Output current:	173 A RMS
Protection:	IP20

Frequently Asked Questions about HMV01.1E-W0075-A-07-NNNN

Q: What type of power supply module is the HMV01.1E-W0075-A-07-NNNN and who manufactures it?

A: The HMV01.1E-W0075-A-07-NNNN is a feeding type power supply module manufactured by Bosch Rexroth.

Q: What are the main sections included in the design of the HMV01.1E-W0075-A-07-NNNN power supply module?

A: The HMV01.1E-W0075-A-07-NNNN power supply module design includes interfaces for signal processing, a control panel, and power connections including control voltage.

Q: What type of protection and cooling system does the HMV01.1E-W0075-A-07-NNNN have?

A: The HMV01.1E-W0075-A-07-NNNN has an IP20 degree of protection and an integrated cooling fan to expel hot air and draw in cool air.

Q: What are the input and output voltage specifications for the HMV01.1E-W0075-A-07-NNNN?

A: The HMV01.1E-W0075-A-07-NNNN requires input from a 3 x AC 380 to 480 V power source and delivers an output of DC 700 V.

Q: What is the short circuit rating and the input and output current of the HMV01.1E-W0075-A-07-NNNN?

A: The HMV01.1E-W0075-A-07-NNNN has a short circuit rating of 42000 A rms, an input current of 128 A, and an output current of 173 A rms.

Internal Product Review

‘‘The hmv01.1e-w0075-a-07-nnnn power supply module impresses with its robust design and efficient power delivery. With a rated current of 75A, it ensures reliable performance in industrial applications. The power supply requires an input current of 128 A and provides output current of 173 A rms.’’
