Home Bosch Rexroth Indramat HDS Series HDS05.2-W300N

HDS05.2-W300N

Name: HDS05.2-W300N
Brand: Bosch Rexroth Indramat
Price: 420 USD
Availability: InStock
Rating: 4.6 (28 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships in 3 Days

Current response time:

3 Minutes 52 Seconds

The HDS05.2-W300N by Bosch Rexroth offers precise motor control with a peak current of 300 A and internal fan cooling. Its IP10-rated housing and 500 VAC output ensure robust industrial performance.

Preparing your secure checkout page...

Warranty

Wake Industrial Warranty

Shipping

Payment

Surplus

Have a HDS05.2-W300N to sell?

To Speak to a sales representative for pricing and lead time:

Phone

1-888-551-3082

International

1-919-443-0207

sales@wakeindustrial.com

Description
Revisions
Specs
FAQ

Product Description

The HDS05.2-W300N drive controller by Bosch Rexroth is designed to precisely drive any motor in an industry. This is a product line of the HDS05 series which can be considered very reliable in function. Some of the features of this component include a rated current of 300 A, internal air blower cooling, and resistance to many types of AC motors such as MKD, MHD, 1MB, and 2AD. It has a 530-670 VDC input and 500 VAC output, so it is quite appropriate for rather demanding motor control tasks.

The HDS05.2-W300N drive controller has a peak current of 300 A with continuous current ratings of 175 A at 4 kHz and 100 A at 8 kHz. It contains an integrated fan that maintains proper cooling to maintain optimum performance even in high-demand situations. The maximum input current with power loss is 1200 W. The unit is housed in an IP10-rated cabinet for basic protection. The HDS05.2-W300N drive controller is built using insulation class C and adheres to DIN VDE 0110 standards. It can operate in a temperature range of 5 degrees C up to 45 degrees C and de-rated to 55 degrees C. With an approximate weight of 25 kg, this drive's controller is compact and capable of handling huge loads. The device comes in separate firmware versions as the firmware is not included but is necessary for use with the device.

Designed to work seamlessly with automation systems, the HDS05.2-W300N provides analog command communication and is of modular structure. It comes pre-configured with plug-in modules that are easily customized. These adapt their design to various specific tasks in controlling motors. Safe operation is important, and safety instructions have to be followed especially with electrical or pressurized components. The appropriate protective equipment should be provided to personnel.

HDS05.2-W300N Technical Specifications

Rated Current:	300 A
Maximum Operating Temperature (De-rated):	55 degrees C
Continuous Current (4 kHz):	175 A
Cooling Type:	Internal Air Blower
Input Voltage:	530-670 VDC
Output Voltage:	500 VAC
Power Loss (Max):	1200 W
Housing Protection:	IP10
Insulation Class:	Class C (DIN VDE 0110)
Operating Temperature Range:	5 degrees C to 45 degrees C

Frequently Asked Questions about HDS05.2-W300N

Q: How does the built-in fan enhance the HDS05.2-W300N?

A: The fan ensures optimal cooling, preventing overheating during high-demand tasks. It prolongs the controller's lifespan under continuous use.

Q: Why is the modular structure of the HDS05.2-W300N important?

A: The modular design allows easy customization with plug-in modules, adapting to various motor control needs effortlessly.

Q: How does the HDS05.2-W300N ensure electrical safety?

A: With insulation class C (DIN VDE 0110), it offers high electrical insulation, ensuring operator and system safety.

Q: Why does the HDS05.2-W300N operate at 8 kHz frequency?

A: The 8 kHz frequency enhances motor control precision, especially in demanding applications requiring fine-tuned speed and torque.

Q: What benefits does the IP10-rated housing provide for HDS05.2-W300N?

A: The IP10 housing offers basic protection against large particles, ensuring consistent performance in controlled environments.

Internal Product Review

‘‘The Bosch Rexroth HDS05.2-W300N drive controller excels in industrial automation with its 300 A peak current and 530-670 VDC input. Features like internal blower cooling, insulation class C, and customizable plug-in modules ensure reliable, flexible performance, making it a top choice for high-demand motor control.’’
