Product Description
The HDS04.2-W200N-HA01-01-FW is one of the several HDS series of drive controllers. The drive controller from Bosch Rexroth has a line code of 4. The device comes equipped with two type plates that give out details of the basic unit and the complete configuration. This product has a peak current rating and a continuous current rating of 200A. It also has a power consumption of 30W for signal processing from a +/-26V source. The unit makes use of an analog interface with 1.2W power consumption for communication. The device is compatible with an HZF power connection module. The controller must not be used in machinery such as elevators that transport people, construction cranes or refinery plants.
The drive controller might experience dangerous movements due to the wrong or inappropriate operation of equipment. The controller must be installed within an altitude of 1,000m above sea level. This drive controller from the DIAX04 family is used for controlling electric motors as well as monitoring their operations. If multiple controllers are mounted together, the ones with the higher current and power needs must be placed closer to the supply unit. The axis should be equally distributed on either side of the power supply as much as possible. The HDS04.2-W200N-HA01-01-FW can be shipped globally with a warranty period of one year.
The mounting rail on which the controller is hung must be fastened in every other slot with an M5 screw that has a tightening torque of 4Nm. The ground connection must be established using a grounding clip at the bottom of the drive controller. The product should be mounted in the vertical orientation. The device utilizes the operation of a built-in blower for internal air circulation. The drive performance tends to get affected if the maximum ambient operating temperature goes beyond 45°C. The unit has a tolerance level of +/-15%.
