HDS03.2-W100N

Name: HDS03.2-W100N
Brand: Bosch Rexroth Indramat
Price: 281 USD
Availability: InStock
Rating: 4.5 (37 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911190228

Unused Original Box Pricing Available!

In-Stock, Ships in 3 Days

Current response time:

4 Minutes 57 Seconds

The HDS03.2-W100N Servo Controller is manufactured by Rexroth Indramat Bosch. This controller is cooled by an Internal Blower, and has a rated current of 100A. This HDS controller is not equipped with Command Communication and the Controller Family is DIAX04.

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

Bosch Rexroth is a trusted manufacturer of automation technologies and motion control products.

The HDS03.2-W100N is a drive control system that enables the formation of a compact drive package by integrated AC drives in an efficient manner. The drive controller has a module based structure and is used with different models of industrial motors. These models include the 1MB, MKD, and MHD motors produced by the company. The device enables precise speed and position control in these motors. Industries with dynamic requirements benefit from this platform. Typically, this drive control system finds its application in textile machinery, woodworking equipment, printing machinery, machine tools, handling tools, packaging machines, and paper manufacturing equipment. This device should be used in areas with a temperature range between 5 ᵒC to 45 ᵒC. For transporting and storing the device, a temperature range between -30 ᵒC to 85 ᵒC is suitable.

The HDS03.2-W100N is compatible with the HVR and HVI supply modules. These modules are used to supply an optimum supply or power and signal voltages to the drive controller. For high performance requirements, the device can be integrated with the HZF power connection module. This model has a weight of only 11 kg which makes it easy to handle, install, and transport. A 1000 meters elevation range is suitable for this device’s operation. This drive controller can be used for general as well as very specific applications. For specific applications, various plug-in modules can be installed in the empty slots provided in the device. The HDS03.2-W100N makes data exchange with a PLC possible because of dedicated I/O cards. The single GDS 1.1 measuring system can also be integrated with the device using the DFF01.1M card. The HDS03.2-W100N can be shipped to any address worldwide with a one-year warranty period from Wake Industrial.

HDS03.2-W100N Technical Specifications

Command Communication:	Not Equipped
Maximum installation height without reduction of rated data:	1000 meters above sea level.
Rated current:	100A
Cooling mode :	Internal air blower
Weight:	11kg
Maximum current:	100A
Maximum permissible ambient temperature with de-rated data:	550C
Insulation classification :	Class C according to DIN VDE 0110
Protection class:	IP10
Power consumption for signal processing:	25A

Frequently Asked Questions about HDS03.2-W100N

Q: In what industrial application can the HDS03.2-W100N be used?

A: The combination of the HDS03.2-W100N with the MKD, MHD, 1MB and the 2AD AC motor froms a rapid response drive system that is perfect for a wmachine tools, printing machines, robotic applications and handling machines. This controller only be used with applications specified in the documentation supplied with the contoller.

Q: Is the HDS03.2-W100N covered by a documentation?

A: Every HDS03.2-W100N controller purchased from our store is covered by a one month warranty. This warranty ensures that the customer does not bear the cost of any damage that occur when the contoller is properly handled.

Q: Can the HDS03.2-W100N withstand harsh environmental conditions during operation?

A: The housing of the HDS03.2-W100N will only protect the controller against touch by hand or any other foreign solid substances larger than 50 millimeters. For effective protection during operations, the controller must be installed in an additional control cabinet that can meet at least the IP54 protection class.

Q: Is the HDS03.2-W100N shipped immediately?

A: Confirmed ordered are processed and shipped within 48 hours. The delivery of the HDS03.2-W100N is handled by trusted delivery companies such as FedEx, DHL, and UPS.

Q: How does the HDS03.2-W100N communicate error messages to the operator?

A: The HDS03.2-W100N has the ability to independently detect operational error. Error messages can be communicated to operators through the H1 status display on the from of the drive controller.
