HDS03.2-W075N-HS80-01-FW

Name: HDS03.2-W075N-HS80-01-FW
Brand: Bosch Rexroth Indramat
Price: 433 USD
Availability: InStock
Rating: 4.7 (15 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

In-Stock, Ships 3-5 Days

Call for Expedited Shipping and Product Condition Options

The Bosch Rexroth HDS03.2-W075N-HS80-01-FW drive controller delivers 75A rated current and integrates optical fiber communication for high-speed data transmission, ensuring real-time motor control. It supports SERCOS and efficient heat management.

Request a Quote Request Repair

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

The HDS03.2-W075N-HS80-01-FW drive controller from Bosch Rexroth is tailored for high-end tasks in industrial automation. Known for its efficient motion control systems, incorporates the controller in the DIAX04 family. This drive controller is capable of complex operations. The drive controller has a current of 75A and includes SERCOS communication interfaces for real-time applications. It is often used together with motors such as 2AD, MKD, and MHD, thus being applied to machines that have reasonable requirements for motor precision control.

The HDS03.2-W075N-HS80-01-FW drive controller is designed with internal air cooling and a built-in blower to manage heat efficiently. It performs optimally within ambient temperatures ranging from 5 degrees C to 45 degrees C ensuring consistent operation. The device accommodates cabinet mounting and can be fitted into existing setups. Fiber optic communication is one of the major benefits of this model since it expedites data transmission regardless of the extent of the network which is important in real-time controlling applications. The HDS03.2-W075N-HS80-01-FW drive controller also has a power loss of approximately 220W, and this amount of energy loss is still low for the given unit relative to the power ratings held by the unit. Weighing around 11kg weight, it is robust yet manageable during installation and maintenance.

The HDS03.2-W075N-HS80-01-FW also supports a variety of configurable modules, including a command communication module and software. This allows users to customize it for specific operational needs. Additional capacitor (HZK) modules are recommended for applications with frequent start-stop cycles of energy storage. Provides and protects against overload. The brake resistor (HZB) is essential for managing the energy generated during braking, especially in non-regenerative power systems. The electrical connection module (HZF) ensures safe and stable electrical control. With an IP10 protection rating, the unit provides basic protection against large particles. This ensures durability in controlled environments.

HDS03.2-W075N-HS80-01-FW Technical Specifications

Rated Current:	75A
Brake Resistor Support:	Supported (HZB)
Power Loss:	220W
Communication Interface:	SERCOS
Operating Temperature Range:	5 degrees C to 45 degrees C
Mounting Type:	Cabinet mounting
Weight:	11 kg
Protection Rating:	IP10
Data Transmission:	Optical fiber communication
Capacitor Module Support:	Supported (HZK)

Frequently Asked Questions about HDS03.2-W075N-HS80-01-FW

Q: Why is a brake resistor necessary in HDS03.2-W075N-HS80-01-FW?

A: The brake resistor in the HDS03.2-W075N-HS80-01-FW dissipates excess energy during braking, preventing system overload. It's vital for non-regenerative power systems.

Q: How does optical fiber communication improve performance in HDS03.2-W075N-HS80-01-FW?

A: The optical fiber communication in the HDS03.2-W075N-HS80-01-FW ensures faster, real-time data transfer. This is crucial for maintaining accurate control in high-speed operations.

Q: How does internal air cooling benefit the HDS03.2-W075N-HS80-01-FW?

A: The internal air cooling with a blower in the HDS03.2-W075N-HS80-01-FW efficiently regulates temperature. This helps maintain operational stability under varying loads.

Q: What role does the capacitor module play in HDS03.2-W075N-HS80-01-FW?

A: The capacitor module in the HDS03.2-W075N-HS80-01-FW supports energy storage during frequent starts and stops. It helps avoid power surges and enhances stability.

Q: Why is SERCOS interface used in HDS03.2-W075N-HS80-01-FW?

A: The SERCOS interface in the HDS03.2-W075N-HS80-01-FW ensures precise synchronization and high-speed communication. This is essential for coordinated motion control in automation systems.

Internal Product Review

‘‘The Bosch Rexroth HDS03.2-W075N-HS80-01-FW is an efficient choice for industrial automation. Its 75A rated current, optical fiber communication, and internal air cooling ensure reliable, real-time motor control. Configurable software modules enhance versatility, making it ideal for high-precision applications requiring customization.’’
