HDS03.1-W100N-H

Name: HDS03.1-W100N-H
Brand: Bosch Rexroth Indramat
Price: 230 USD
Availability: InStock
Rating: 4.5 (35 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911310560

In-Stock, Ships 3-5 Days

TheHDS03.1-W100N-H servo drive controller is a highly sophisticated device designed by Bosch Rexroth Indramat. The controller combines with MKD, 1MB, MHD, and 2AD Rexroth AC motors to form rapid response automatization system. The controller has a modular design, and is delivered to customers as a fully configured unit.

Preparing your secure checkout page...

Product Description

The HDS03.1-W100N-H is a state-of-the-art industrial drive controller manufactured by Rexroth Indramat which is internationally renowned for the production of cost-efficient and durable industrial machine products. This controller is has a modular design that makes it possible for it to be flexibly combined with other AC drives to sophisticated drive packages that can be supported by on supply unit. The drive controller is compatible with different Bosch Rexroth motor designs including the MKD, MHD, 1MB and 2 AD motor series. The controller is also capable of supporting different industrial machines including printing and packaging machines, textile machines, robotic machines and handling machines. During operation, the HDS03.1-W100N-H industrial is intended for connection to either the HVE or HVR supply modules. These modules are also manufactured by Bosch Rexroth and can supply all the signals and the power voltages the controller requires. If the controller is used with a power supply system that is not capable of regeneration, and if the drive performance required is very high, operators should consider integrating the HZB additional braking resistor to control the energy generated from braking. Also, if the controller is to be used for high continuous start-stop operations, it may be necessary to use the HZK additional capacitor with the controller. The electronic components of the HDS03.1-W100N-H industrial controller should be protected from electrostatic loads or persons or object coming in contact with it, this can be done by ensuring all objects are properly discharged by grounding before coming in contact with the controller. In the case of operational errors, the HDS03.1-W100N-H controller generates drive error messages through the SERCOS interface and the H1 status display on the front of the controller unit.

HDS03.1-W100N-H Technical Specifications

Version :	1
Protection class:	IP10
Peak current:	100A
Switching Frequency:	4 and 8kHz
Continuous current at 4kHz switching frequency :	50A
Continuous current at 8kHz:	35A
Power loss at continuous current:	280W per axis
Weight:	11kg
Power consumption for signals processing:	25W
Insulation classification:	C

Frequently Asked Questions about HDS03.1-W100N-H

Q: Can the HDS03.1-W100N-H controller be used at ambinet temperature higher than 45 degrees?

A: It is possible to use the HDS03.1-W100N-H controller at a temperature as high as 55 degrees. However above 45 degrees there is a significant reduction in the rated data of the controller

Q: What does the digital input/output card used with the HDS03.1-W100N-H controller do?

A: The digital interface cards used as one of the additional plug-in module of the HDS03.1-W100N-H controller is used for a bi-directional exchange of data. Each interface card has 15 inputs and 16 outputs.

Q: Can the HDS03.1-W100N-H controller withstand harsh environmental conditions?

A: No. The housing of the HDS03.1-W100N-H controller is only designed to provide protection against large solid materials. Operators should avoid using the controller in conditions that exposes it to dust, moisture or extreme vibrations.

Q: Is the HDS03.1-W100N-H controller easy to control?

A: The operation of the HDS03.1-W100N-H controller is designed to be very easy and stright forward, however to pervent accidents, only well trained engineers who have gone through the documentation supplied with the controller.

Q: Does wake industrial offer waranty on the HDS03.1-W100N-H controller?

A: Yes, the HDS03.1-W100N-H controller is covered by a 12 month warranty. This warranty covers any damage that occurs even when the controller is appropriately used.
