HDS02.2-W040N-H

Name: HDS02.2-W040N-H
Brand: Bosch Rexroth Indramat
Price: 308 USD
Availability: InStock
Rating: 4.6 (28 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911310560

In-Stock, Ships 1-2 Days

Call for Expedited Shipping and Product Condition Options

The HDS02.2-W040N-H servo drive controller is a highly sophisticated device designed by Bosch Rexroth Indramat. The controller combines with MKD, 1MB, MHD, and 2AD Rexroth AC motors to form rapid response automatization system. The controller has a modular design, and is delivered to customers as a fully configured unit.

Preparing your secure checkout page...

Description
Revisions
Specs
FAQ

Product Description

Bosch Rexroth is a global engineering powerhouse that have been in operation for more than three decades. The company specializes in the production and distribution of high efficiency and sophisticated automation and automation control products that play a major role in ensuring operation efficiency in industries all over the world. The HDS02.2-W040N-H drive controller is one of the finest productions of the company. The controller is a modular device designed for Rexroth Motor series especially the MKD, MHD, 1MB, and 2 AD ac motors. The operation of the drive controller has a fixed configuration and is able to activate two motors. The controller belongs to the DIAX04 controller family and operates with the SERCOS command communication interface. The HDS02.2-W040N-H industrial controller is supplied already configured by Bosch Rexroth, however it is still necessary to ensure that only industrial professionals are allowed to interact with the controller. The drive controller is equipped with two ground connections to the supply module, one grounding connection is at the back wall of the controller unit while the other grounding connection is done through grounding clips in front of the unit. The electrical cables required for motor power connection and feedback connections are available are ready made cable products. Operators are required to order these cables separately for use with the drive controller. The HDS02.2-W040N-H industrial drive controller should be fastened to the control cabinet through the SUP-MO1-HD mounting rail. This mounting rail is only available is a length of 750 millimeters and must be shortened as needed at delivery. While installing the controller into the control cabinet, a minimum clearance of 100 millimeters is required around the controller to allow for the easy movement of cool air.

HDS02.2-W040N-H Technical Specifications

Version :	2
Protection class:	IP10
Peak current:	40A per axis
Switching Frequency:	4 and 8kHz
Continuous current at 4kHz switching frequency :	15kHz
Continuous current at 8kHz:	10A
Power loss at continuous current:	110W per axis
Weight:	8kg
Power consumption for signals processing:	40W
Insulation classification:	C

Frequently Asked Questions about HDS02.2-W040N-H

Q: What type of industrial application is the HDS02.2-W040N-H controller suitable for?

A: The HDS02.2-W040N-H controller has a modular design and can be adapted to specific function through the use of plug-in modules. Industrial applications compatible with this controller include the paper processing machines, food processing machines, handling devices and lots more.

Q: What does the HSM software module do in the HDS02.2-W040N-H controller?

A: The HSM software module contains the operating software of the controller and also stores all drive parameters. The firmware used with the HDS02.2-W040N-H controller should depend on the selected configuration and the desired functions.

Q: Is the HDS02.2-W040N-H controller sensitive to electrostatic loads?

A: Yes. Electrostatic loads can damage the HDS02.2-W040N-H drive controller when discharging. This damage can cause errors when the controller is triggering motors. Objects coming in contact with components and circuit boards must be discharged by means of grounding/

Q: What is the H1 display unit on the HDS02.2-W040N-H controller do?

A: The H1 display unit is on the front panel of the HDS02.2-W040N-H controller. It communicates operational status, warnings and operational errors. The display unit operates in real time and should be regularly monitored by operators.

Q: what type of mounting rail should be used with the HDS02.2-W040N-H controller?

A: The mounting of the HDS02.2-W040N-H controller into the control cabinet should be done with the mounting rail with type designation SUP-MO1-HD. The mounting rail is only available in a length of 750mm and must be shortened as needed as delivery.
