HDD12.2-W040N

Name: HDD12.2-W040N
Brand: Bosch Rexroth Indramat
Price: 189 USD
Availability: InStock
Rating: 4.6 (21 reviews)

Straightforward Pricing: No Rush Fees, No Credit Card Fees

MPN: R911283207

Available

Current response time:

4 Minutes 8 Seconds

The HDD12.2-W040N Servo Controller is manufactured by Rexroth Indramat Bosch. This controller has an Internal Air Cooling and a rated current of 40. The Controller Family is DIAX04 and a Command Communication of SERCOS.

Preparing your secure checkout page...

Warranty

Wake Industrial Warranty

Shipping

Payment

Surplus

Have a HDD12.2-W040N to sell?

To Speak to a sales representative for pricing and lead time:

Phone

1-888-551-3082

International

1-919-443-0207

sales@wakeindustrial.com

Description
Revisions
Specs
FAQ

Product Description

The HDD12.2-W040N is a POWERDRIVE HDD drive controller manufactured by the Rexroth Indramat Company. It features a modular concept that enables a flexible combination of AC drives to create a compact drive package using a single standard supply unit. This type together with ADP and MHP AC motors creates rapid-responsive drives. This allows it to be used as a main or servo drive with extensive functionality for applications such as packaging machines, robotics, and handling machines. The HDD12.2-W040N is intended to be connected to an HVR or HVE supply module that supplies all the required signal voltages and power.

This Rexroth Indramat drive controller is in the 12 series of POWERDRIVES, version 2 and features an air cooling system and a current of 40 A. the technical data of the drive is a 40 A peak current a continuous current of 20 A, a maximum power loss of 125 W, and power consumption of 20 W for signal processing. It has a weight of 7.5kg. The allowed conditions for use include an ambient temperature of 5 to 45 degrees, a storage/transport temperature of -30 to 85 degrees, a maximum setup height of 1000 meters above sea level, and a permissible relative humidity of 95% without condensation.

The HDD12.2-W040N has a protection category of IP 10 and should be installed in a control cabinet that meets this category demands. It is necessary to use a cooler to maintain the ambient temperature at 45 degrees. This causes water condensation which, if it comes to contact with the drive can cause damage. You should use an air duct to collect the water. To avoid condensation, set the temperature of the cooler to 40 degrees or lower. This product is available from Wake Industrial with a one-year warranty period.

HDD12.2-W040N Technical Specifications

Command Communication:	SERCOS
Operating Temperature Range:	(+5 to +45) degree centigrade
Maximum Current :	40 A
Version:	2
Cooling:	Air Cooling System
Continuous Current:	20 A
Maximum Power Loss:	125 W
Power Consumption For Signal Processing:	20 W
Weight:	7.5 kg
Protection Rating:	IP10

Frequently Asked Questions about HDD12.2-W040N

Q: What is the modular concept of the HDD12.2-W040N?

A: The HDD12.2-W040N features a modular concept, allowing a flexible combination of AC drives to form a compact drive package using a single standard supply unit.

Q: Which AC motors are compatible with the HDD12.2-W040N?

A: The HDD12.2-W040N can be paired with ADP and MHP AC motors, creating rapid-responsive drives suitable for a range of applications.

Q: What are the primary applications of the HDD12.2-W040N?

A: The drive can serve as a main or servo drive, making it ideal for use in packaging machines, robotics, and handling machines.

Q: Which supply modules can the HDD12.2-W040N be connected to?

A: The HDD12.2-W040N is designed to connect to either an HVR or HVE supply module, which provides the necessary signal voltages and power.

Q: What are the environmental conditions suitable for the HDD12.2-W040N?

A: The drive operates best at ambient temperatures of 5 to 45 degrees, with a storage/transport range of -30 to 85 degrees, and at 95% relative humidity without condensation.
